APC Easy UPS BV 650VA UPS, AVR, Universal Outlet, 230V (BV650I-MSX)
| Output | |
| Output power capacity | 375 Watts / 650VA |
| Max Configurable Power (Watts) | 375 Watts / 650VA |
| Nominal Output Voltage | 230V |
| Output Frequency (sync to mains) | 50/60 Hz +/- 1 Hz Unsynchronised |
| Topology | Line interactive |
| Waveform type | Stepped approximation to a sine wave |
| Output Connections | (4) Universal receptacle |
| Transfer Time | 6 ms typical : 10 ms maximum |
| Input | |
| Nominal Input Voltage | 230V |
| Input frequency | 50/60 Hz +/- 5 Hz Auto-sensing |
| Input Connections | BS1363A British |
| Cord Length | 1.5meters |
| Input voltage range for main operations | 170 – 280V |
| Number of Power Cords | 1 |
| Batteries & Runtime | |
| Battery type | Lead-acid battery |
| Expected Battery Life (years) | 3 – 5 |
| Efficiency | View Efficiency Graph (Available in Technical Tab on site) |
Features of the APC Easy UPS BV 650VA UPS, AVR, Universal Outlet, 230V (BV650I-MSX)
Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.
Sleek design
Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.
Cold-start capable
Provides temporary battery power when the utility power is out.
Availability
Advanced Safety Features
Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Protection
Battery backup and surge protection
Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes.
Manageability
Audible alarms
Provides notification of changing utility power and UPS power conditions
LED Indicators
Provide easy-to-read status of the unit and utility power conditions.
