Canon DX4745i Copier
| TYPE | Monochrome Laser Multifunctional |
| CORE FUNCTIONS | Standard: Print, Copy, Scan, Send, Store Optional: Fax |
| PROCESSOR | 1.75 GHz Dual Core Processor |
| CONTROL PANEL | 10.1″ TFT LCD WSVGA Color Touch-panel |
| MEMORY | 3.0 GB RAM |
| HARD DISK DRIVE | Standard: 250 GB Maximum: 1 TB |
| PRINT RESOLUTION | 1200 dpi x 1200 dpi |
| INTERFACE CONNECTION | Network Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n) Optional: NFC, Bluetooth Low Energy Others Standard: USB 2.0 x1 (Host), USB 3.0 x1 (Host), USB 2.0 x1 (Device) Optional: Copy Control Interface |
| PAPER CAPACITY (LETTER, 20 LB. BOND) | Standard: 1,200 Sheets Maximum: 6,350 Sheets |
| PAPER SOURCES (LETTER, 20 LB. BOND) | Standard: Two 550-sheet Paper Cassettes, 100-sheet Stack Bypass Optional: Two 550-sheet Paper Cassettes (Cassette Feeding Unit-AN1), 2,450-sheet Paper Deck (High Capacity Cassette Feeding Unit-B1), 2,700-sheet Paper Deck (Paper Deck Unit-F1) |
| PAPER OUTPUT CAPACITY (LETTER, 20 LB. BOND) | Standard: 250 Sheets Maximum: 3,350 Sheets (with Buffer Pass-N1 + Staple Finisher-Y1 or Booklet Finisher-Y1) |
| FINISHING CAPABILITIES | Standard: Collate, Group With Finishers: Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand |
| SUPPORTED MEDIA TYPES | Upper/Lower Cassette: Thin, Plain, Recycled, Color, Heavy, Pre-punched Multi-purpose Tray: Thin, Plain, Recycled, Color, Heavy, Pre-punched, Bond, Transparency, Label, Envelope |
| SUPPORTED MEDIA SIZES | Upper Cassette: Legal, Letter, Letter-R, Executive, Statement-R, Custom Size (5-1/2″ x 7-1/8″ to 11-3/4″ x 15-3/8″) Lower Cassette: 11″ x 17″, Legal, Letter, Letter-R, Executive, Statement-R, Custom Size (5-1/2″ x 7-1/8″ to 11-3/4″ x 17″), Envelope1: [No.10 (COM10), Monarch, DL, ISO-C5] Multi-purpose Tray: 11″ x 17″, Legal, Letter, Letter-R, Executive, Statement-R, Envelope [No.10 (COM10), Monarch, DL, ISO-C5], Custom Size/Free Size (3-7/8″ x 5-7/8″ to 11-3/4″ x 17″) |
| SUPPORTED MEDIA WEIGHTS | Upper/Lower Cassette: 16 lb. Bond to 80 lb. Cover (60 to 220 g/m2) Multi-purpose Tray: 14 lb. Bond to 80 lb. Cover (52 to 220 g/m2) Duplexing: 16 lb. Bond to 28 lb. Bond (60 to 105 g/m2) |
| PRINT/COPY SPEED | Up to 45 ppm (Letter), Up to 32 ppm (Letter-R), Up to 25 ppm (Legal), Up to 22 ppm (11″ x 17″) |
| WARM-UP TIME | From Power On: Approx. 24 Seconds2 From Sleep Mode: Approx. 10 Seconds3 Quick Startup Mode: Approx. 4 Seconds4 |
| DIMENSIONS (W x D x H) | 24″ x 28-1/2″ x 36-3/4″ (608 mm x 722 mm x 932 mm) |
| INSTALLATION SPACE (W x D x H) | Basic: 44″ x 45-5/8″ (1,116 x 1,160 mm) (with Platen Cover-Y2 + Multi-purpose Tray open/extension tray extended + Paper Cassette open) 44″ x 46″ (1,116 x 1,169 mm) (with Single Pass DADF-C1 + Multi-purpose Tray open/ extension tray extended + Paper Cassette open) 44″ x 45-7/8″ (1,116 x 1,166 mm) (with DADFBA1 + Multi-purpose tray open/extension tray extended + Paper Cassette open) Fully Configured: 71-3/8″ x 46″ (1,811 x 1,169 mm) (with Single Pass DADF-C1 + Paper Deck Unit-F1 + Booklet Finisher-Y1 with extension tray extended and Saddle unit drawn) 71-3/8″ x 45-7/8″ (1,811 x 1,166 mm) (with DADF-BA1 + Paper Deck Unit F1 + Booklet Finisher-Y1 with extension tray extended and Saddle unit drawn) |
| WEIGHT5 | With Single Pass DADF-1: Approx. 193.8 lb. (87.9 kg) |
| PRINT SPECIFICATIONS | |
| STANDARD PAGE DESCRIPTION LANGUAGES | UFR II, PCL®6, Adobe® PS® 3 |
| SUPPORTED FILE TYPES FOR DIRECT PRINT | PDF, TIFF, JPEG, EPS, XPS |
| PRINTING FROM MOBILE AND CLOUD-BASED SERVICES | A range of standard and optional software and MEAP-based solutions (including AirPrint, Mopria, Universal Print by Microsoft, Canon PRINT Business, and uniFLOW Online) are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements. Please contact your sales representative for further information. |
| FONTS | PCL Fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T (Japanese, Korean, Simplified and Traditional Chinese),6 Barcode Fonts7 PS Fonts: 136 Roman |
| OPERATING SYSTEM 8 | UFRII/PS: Windows® 7/8.1/10/Server 2008/Server 2008 R2/Server 2012/Serve 2012 R2/ Server 2016/Server 2019, Mac OS X (10.10 or later) PCL: Windows® 7/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/ Server 2016/Server 2019 PPD: Windows® 7/8.1/10, Mac OS X (10.9 or later) |
| COPY SPECIFICATIONS | |
| FIRST-COPY-OUT-TIME | As fast as 3.8 seconds |
| COPY RESOLUTION (dpi) | 600 x 600 |
| MULTIPLE COPIES | Up to 9,999 Copies |
| COPY EXPOSURE | Automatic or Manual (9 Levels) |
| MAGNIFICATION | 25%-400% (1% Increments) |
| PRESET REDUCTION / ENLARGEMENT | 25%, 50%, 64%, 73%, 78%, 100%(1:1), 121%, 129%, 200%, 400% |
| SCAN SPECIFICATIONS | |
| TYPE | Standard Single-Pass Duplexing Automatic Document Feeder |
| DOCUMENT FEEDER PAPER CAPACITY | Single Pass DADF: Up to 200 Sheets |
| DOCUMENT FEEDER SUPPORTED MEDIA SIZES | 11″ x 17″, Legal, Letter, Letter-R, Statement, Statement-R |
| DOCUMENT FEEDER SUPPORTED MEDIA WEIGHTS | Single Pass DADF-C1 Single-sided Scanning: 13.3 lb. Bond to 80 lb. Cover (50 to 220 g/m2) Double-sided Scanning: 13.3 lb. Bond to 80 lb. Cover (50 to 220 g/m2) |
| PLATEN ACCEPTABLE ORIGINALS | Sheet, Book, 3-Dimensional Objects |
| PLATEN SUPPORTED MEDIA SIZE | UP to 11-3/4″ x 17″ (297 mm x 431.8 mm) |
| PULL SCAN | Color Network ScanGear2 for both Twain and WIA Supported OS: Windows® 7/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016 |
| SCAN RESOLUTION | Push: Up to 600 x 600 Pull: Up to 600 x 600 |
| SCAN TO MOBILE DEVICES AND CLOUD-BASED SERVICES | A range of solutions is available to provide scanning to mobile devices and cloud-based services depending on your requirements. |
| SCAN SPEED (LETTER) | Single Pass DADF-C1 Single-sided Scanning BW/Color: 135 ipm (300 dpi)/80 ipm (600 dpi) Double-sided Scanning BW/Color: 270 (300 dpi), 160 (600 dpi) |
| SEND SPECIFICATIONS | |
| DESTINATION | Standard: E-mail/Internet FAX (SMTP), SMB 3.0, FTP, WebDAV, Mail Box Optional: Super G3 Fax, IP Fax |
| ADDRESS BOOK | LDAP (2,000)/Local (1,600)/Speed dial (200) |
| SEND RESOLUTION | Push: Up to 600 x 600 Pull: Up to 600 x 600 |
| COMMUICATION PROTOCOL | File: FTP (TCP/IP), SMB 3.0 (TCP/IP), WebDAV Email: SMTP, POP3 |
| FILE FORMAT | TIFF, JPEG, PDF (Compact, Searchable, Apply Policy, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word) |
| FAX SPECIFICATIONS | |
| MAXIMUM NUMBER OF LINES | 4 |
| MODEM SPEED | Super G3: 33.6 Kbps G3: 14.4 Kbps |
| COMPRESSION METHOD | MH, MR, MMR, JBIG |
| RESOLUTION | 400 x 400, 200 x 400, 200 x 200, 200 x 100 |
| SENDING / RECORDING SIZE | Statement-R to 11″ x 17″ |
| FAX MEMORY | Up to 30,000 Pages (2,000 Jobs) |
| SPEED DIALS | Max. 200 |
| GROUP DIALS / DESTINATIONS | Max. 199 Dials |
| SEQUENTIAL BROADCAST | Max. 256 Addresses |
| MEMORY BACKUP | Yes |
| STORE SPECIFICATIONS | |
| MAIL BOX SIMPLE (NUMBER SUPPORTED) | 100 User In-boxes, 1 Memory RX In-box, 50 Confidential Fax Inboxes, 30,000 Maximum Pages Stored (2,000 Jobs Stored) |
| ADVANCED BOX | Communication Protocol: SMB or WebDAV Supported Client PC: Windows (Windows 8.1/10) Concurrent Connections (Max.) SMB: 64 WebDAV: 3 (Active Sessions) |
| ADVANCED BOX AVAILABLE DISC SPACE | Approx. 16 GB (Standard HDD) Approx. 480 GB (With Optional 1 TB HDD) |
| MEMORY MEDIA | Standard: USB |
| SECURITY SPECIFICATIONS | |
| AUTHENTICATION | Standard: Universal Login Manager, uniFLOW Online Express,9 User Authentication, Department ID Authentication, Access Management System, Device and Function Level Log-in Optional: uniFLOW |
| DATA | Standard: Trusted Platform Module (TPM), Hard Disk Password Lock, Hard Disk Drive Erase, Mail Box Password Protection, Hard Disk Drive Encryption (FIPS140-2 Validated), Verify System at Startup, McAfee Embedded Control10 Optional: Hard Disk Drive Mirroring, IEEE 2600.2 Common Criteria Certification, Data Loss Prevention (Requires uniFLOW) |
| NETWORK | Standard: Encrypted Secure Print, IP/Mac Address Filtering, IPsec, TLS Encrypted Communication (v1.0/1.1/1.2/1.3), SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP, S/MIME, SIEM Integration |
| DOCUMENT | Standard: Secure Watermark, Secure Print, Forced Hold Printing, Adobe LiveCycle® Rights Management ES2.5 Integration, Encrypted PDF, Encrypted Secure Print, Device Signature, User Signature |
| ENVIRONMENTAL SPECIFICATIONS | |
| OPERATING ENVIRONMENT | Temperature: 50 to 86ºF Humidity: 20 to 80% RH (Relative Humidity) |
| POWER REQUIREMENTS | 110-127V, 60Hz, 10.4A |
| POWER CONSUMPTION | Maximum: Approx. 1,500 W Standby: Approx. 39 W11 Sleep Mode: Approx. 0.9 W12 Typical Electricity Consumption (TEC) Rating:13 4751i: 0.71 kWh / 4745i: 0.62 kWh / 4735i: 0.51 kWh / 4725i: 0.34 kWh |
| STANDARDS | ENERGY STAR® Certified Rated EPEAT® Gold |
| CONSUMABLES | |
| TONER | GPR-57 Toner Black |
| TONER YIELD (ESTIMATED @ 6% COVERAGE) | Black: 42,100 Images |
| FOOTNOTES | |
| Envelope Feeder Attachment-D1 is required. Time from device power-on, until copy ready (not print reservation). Time from exiting Sleep mode to when printing is operational. Time from device power on to when the copy icon appears and is enabled to operate on the touch panel display. Includes toner. Requires the optional PCL International Font Set-A1. Requires the optional Barcode Printer Kit-D1. Other operating systems and environments including AS/400, UNIX, Linux, and Citrix may be supported. Some of these solutions are chargeable. SAP Device Types are available via the SAP Market Place. For more information, contact your sales representative. No charge for this solution; however, activation is required. Requires Unified Firmware Platform v3.9 or greater. Reference Value (measured one unit). 0.9 W sleep mode is not available in all circumstances due to certain settings. Based on ENERGY STAR Product Specification for Imaging Equipment Version 3.0. |
|
