Canon has taken care of the optical design, using two aspherical elements and the Super Spectra Coating to minimize aberrations and reduce ghosting and flare. An Optical Image Stabilizer will help ensure sharp imagery, providing up to 4 stops of shake correction or up to 6 stops of Coordinated IS with a compatible camera body. Additionally, the lead screw-type STM AF system is fast enough to keep up with speedy continuous focus while being smooth and quiet enough to work for video.
- Telephoto zoom lens for RF-mount APS-C format mirrorless cameras provides an 88-336mm equivalent focal length range.
- Optical Image Stabilizer technology compensates for up to 4.5 stops of camera shake to better enable taking sharp handheld photos in difficult lighting conditions. When paired with EOS R-series cameras featuring an In-Body Image Stabilizer (IBIS), up to 7 stops of shake correction are provided.
- STM stepping motor offers fast, quiet, smooth, and accurate autofocus performance that is ideal for video recording as well as still shooting.
- Two Ultra-Low Dispersion elements and a Super Spectra Coating minimize ghosting and flare.
- Minimum focusing distance of 28.7″ for working with close-up subjects.
- The compact and lightweight lens weighs just 9.5 oz.
Specifications
Imaging
Lens Mount |
Canon RF |
Sensor Resolution |
Effective: 24.2 Megapixel |
Image Sensor |
22.3 x 14.9 mm (APS-C) CMOS |
Crop Factor |
1.6x |
Image Stabilization |
None |
Built-In ND Filter |
None |
Capture Type |
Stills & Video |
Exposure Control
Shutter Type |
Electronic Shutter |
Shutter Speed |
Electronic Shutter |
1/8000 Up to 30 Seconds |
Electronic Front Curtain Shutter |
1/4000 Up to 30 Seconds |
Bulb/Time Mode |
Bulb Mode, Time Mode |
ISO Sensitivity |
Photo/Video |
100 to 32,000 (Extended: 51,200) |
Metering Method |
Center-Weighted Average, Evaluative, Partial, Spot |
Exposure Modes |
Aperture Priority, Manual, Program, Shutter Priority |
Exposure Compensation |
-3 to +3 EV (1/3 EV Steps) |
Metering Range |
-2 to 20 EV |
White Balance |
Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
Continuous Shooting |
Electronic Shutter |
Up to 15 fps for up to 28 Frames (JPEG) / 7 Frames (Raw) |
Electronic Shutter |
Up to 12 fps for up to 42 Frames (JPEG) / 7 Frames (Raw) |
Interval Recording |
Yes |
Self-Timer |
2/10-Second Delay |
Still Image Capture
Aspect Ratio |
3:02 |
Image File Format |
C-RAW, HEIF, JPEG, Raw |
Video Capture
Internal Recording Modes |
H.264/H.265/MPEG-4 |
UHD 4K (3840 x 2160) at 23.98/25/29.97 fps |
1920 x 1080 at 23.98/25/29.97/50/59.94/100/120 fps |
Broadcast Output |
NTSC/PAL |
Built-In Microphone Type |
Stereo |
Interface
Media/Memory Card Slot |
Single Slot: SD/SDHC/SDXC |
Video I/O |
1 x Micro-HDMI Output |
Audio I/O |
1 x 1/8″ / 3.5 mm TRS Stereo Microphone Input on Camera Body |
Other I/O |
1 x USB-C Input/Output |
Wireless |
2.4 / 5 GHz Bluetooth 4.2 Control |
Wi-Fi |
Mobile App Compatible |
Yes |
*As of February 2023: Check with the manufacturer for the most up-to-date compatibility |
Global Positioning (GPS, GLONASS, etc.) |
None |
Display
Size |
3″ |
Resolution |
1,620,000 Dot |
Display Type |
Articulating Touchscreen LCD |
Viewfinder
Type |
Built-In Electronic (OLED) |
Size |
0.39″ |
Resolution |
2,360,000 Dot |
Eye Point |
22 mm |
Coverage |
100% |
Magnification |
Approx. 96x |
Diopter Adjustment |
-3 to +1 |
Focus
Focus Type |
Auto and Manual Focus |
Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF |
Autofocus Points |
Photo |
Phase Detection: 4503 |
Video |
Phase Detection: 3713 |
Autofocus Sensitivity |
-4 to +20 EV |
Flash
Built-In Flash |
Yes |
Maximum Sync Speed |
1/250 Second |
Flash Compensation |
-3 to +3 EV (1/3 EV Steps) |
Dedicated Flash System |
eTTL |
External Flash Connection |
Intelligent Hot Shoe |
Environmental
Operating Temperature |
32 to 72°F / 0 to 40°C |
Operating Humidity |
0 to 85% (Recommended) |
General
Battery Type |
1 x LP-E17 Rechargeable Lithium Polymer, 7.2 VDC, 1040 mAh |
Tripod Mounting Thread |
1 x 1/4″-20 Female (Bottom) |
Dimensions (W x H x D) |
4.6 x 3.4 x 2.7″ / 116.3 x 85.5 x 68.8 mm |
Weight |
13.2 oz / 375 g (With Battery, Recording Media) |
11.6 oz / 328 g (Body Only) |
Canon RF-S 18-45mm F/4.5-6.3 IS STM Lens Specifications
Focal Length |
18 to 45mm (35mm Equivalent Focal Length: 29 to 72mm) |
Maximum Aperture |
f/4.5 to 6.3 |
Minimum Aperture |
f/32 |
Lens Mount |
Canon RF |
Lens Format Coverage |
APS-C |
Angle of View |
74° 20′ to 33° 40′ |
Minimum Focus Distance |
7.9″ / 20 cm |
Maximum Magnification |
0.16x |
Optical Design |
7 Elements in 7 Groups |
Diaphragm Blades |
7, Rounded |
Focus Type |
Autofocus |
Image Stabilization |
Yes |
Filter Size |
49 mm (Front) |
Dimensions (ø x L) |
2.7 x 1.7″ / 68.9 x 44.3 mm |
Weight |
4.6 oz / 130 g |
Canon RF-S 55-210mm F/5-7.1 IS STM Lens (Canon RF) Specifications
Focal Length |
55 to 210mm (35mm Equivalent Focal Length: 88 to 336mm) |
Maximum Aperture |
f/5 to 7.1 |
Lens Mount |
Canon RF |
Lens Format Coverage |
APS-C |
Angle of View |
27° 50′ to 7° 25′ |
Minimum Focus Distance |
2.3′ / 70 cm |
Maximum Magnification |
0.28x |
Optical Design |
11 Elements in 8 Groups |
Diaphragm Blades |
7 |
Focus Type |
Autofocus |
Image Stabilization |
Yes |
Filter Size |
55 mm (Front) |
Dimensions (ø x L) |
2.7 x 3.7″ / 6.9 x 9.4 cm |
Length at Maximum Extension |
5.3″ / 13.5 cm |
Weight |
9.5 oz / 270 g |
