Canon XF605 UHD 4K HDR Pro Camcorder
Combining high-resolution capture with a mobile workflow, the 15x zoom XF605 UHD 4K HDR Pro Camcorder from Canon is a go-to choice for ENG, sports, entertainment, and narrative applications. This compact 1″ CMOS sensor camera with a DIGIC DV 7 engine features high sensitivity, Canon cinema color matrix choices, Canon Log 3, HDR support, and Eye AF and EOS iTR AF X (head detection) autofocus modes. It offers up to UHD 4K60 4:2:2 10-bit capture in a variety of both All-I and Long-GOP XF-AVC and MP4 H.264/H.265 formats with the ability to capture different codecs and rates simultaneously to its dual SD card slots. A Direct Touch Control touchscreen menu, four-channel XLR audio, simultaneous outputs, a USB-C video output, and an iPhone app built on established XF series features such as individual focus, iris, and zoom rings, and built-in ND filters.
Imaging
| Sensor Resolution |
Actual: 13.4 Megapixel (4268 x 3148) |
| Effective: 8.29 Megapixel (3840 x 2160) |
| Image Sensor |
1″-Type CMOS |
| Image Stabilization |
Optical in Integrated Lens |
| Digital |
| Built-In ND Filter |
Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters |
| Capture Type |
Stills & Video |
Exposure Control
| Shutter Type |
Electronic Rolling Shutter |
| Shutter Speed |
1/2000 to 1/4 Second |
| Shutter Angle |
11 to 360° |
| Sensitivity |
f/12 at 2000 lux |
| Minimum Illumination |
1.5 Lux at 1/30 Shutter Speed |
| White Balance |
2000 to 15,000K |
Lens
| Focal Length |
8.3 to 124.5mm (35mm Equivalent Focal Length: 25.5 to 382.5mm) |
| Optical Zoom Ratio |
15x |
| Max Digital Zoom |
30x ( in 1080p) |
| Maximum Aperture |
f/2.8 |
| Minimum Aperture |
f/4.5 |
| Optical Design |
18 Elements in 14 Groups |
| Minimum Focus Distance |
Entire Zoom Range: 2.0′ / 60.0Â cm |
| Wide: 0.4″ / 1.0Â cm |
| Filter Size |
58 mm |
| Control Rings |
Focus |
| Zoom |
| Iris |
| Focus Control |
Autofocus |
| Manual Focus |
Video Capture
| Internal Recording Modes |
MXF/XF-AVC 4:2:2 10-Bit |
| 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [160 to 410 Mb/s] |
| 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s] |
| 1920 x 1080i at 50/59.94 fps [50 to 160 Mb/s] |
| 1280 x 720 at 23.98/25/29.97/50/59.94 fps |
| H.265/MP4 4:2:2 10-Bit |
| 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [135 to 225 Mb/s] |
| 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 Mb/s] |
| 1280 x 720 at 23.98/25/29.97/50/59.94 fps [12 Mb/s] |
| H.265/MP4 4:2:0 10-Bit |
| 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 170 Mb/s] |
| 1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s] |
| 1280 x 720 at 23.98/25/29.97/50/59.94 fps [9 Mb/s] |
| H.264/MP4 4:2:0 8-Bit |
| 3840 x 2160 from 1 to 23.98/25/29.97/50/59.94 fps [150 Mb/s] |
| 1920 x 1080p from 1 to 23.98/25/29.97/50/59.94 fps [35 Mb/s] |
| 1280 x 720 at 23.98/25/29.97/50/59.94 fps |
| External Recording Modes |
SDI/BNC |
| UHD 4K (3840 x 2160) up to 59.94 fps |
| Fast-/Slow-Motion Support |
Yes |
| Gamma Curve |
Canon Log 3, HDR-HLG |
| Built-In Microphone Type |
Stereo |
| Audio Recording |
2-Channel 16-Bit 48 kHz AAC Audio |
| 4-Channel 24-Bit 48 kHz LPCM Audio |
| IP Streaming |
MPEG2 |
| 1920 x 1080 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.0 Mb/s) |
| 1920 x 1080 at 50i, 59.94i (4.0 to 9.0 Mb/s) |
Interface
| Media/Memory Card Slot |
Slot 1: SD/SDHC/SDXC |
| Slot 2: SD/SDHC/SDXC |
| Video I/O |
1 x HDMI 2.0 Output |
| 1 x BNC (12G-SDI) Output |
| Audio I/O |
2 x XLR 3-Pin Input |
| 1 x 1/8″ / 3.5 mm TRS Stereo Input |
| 1 x 1/8″ / 3.5 mm TRS Stereo Headphone Output |
| Power I/O |
1 x Barrel (24VDC) Input |
| Other I/O |
1 x USB-A Output |
| 1 x USB-C |
| 1 x BNC (Genlock, Sync) Input/Output |
| 1 x BNC (Timecode) Input/Output |
| 1 x 2.5 mm Sub-Mini Control |
| 1 x D-Sub 8-Pin Control |
| 1 x RJ45 (LAN) Input/Output |
| Wireless |
2.4 / 5 GHz MIMO Wi-Fi Video Output, Audio Output, Control |
| Global Positioning (GPS, GLONASS, etc.) |
None |
Monitor
| Size |
3.45″ |
| Resolution |
2,760,000 Dot |
| Display Type |
Articulating Touchscreen LCD |
Viewfinder
| Type |
Removable Electronic (OLED) |
| Size |
0.36″ |
| Resolution |
1,770,000 Dot |
Focus
| Focus Type |
Auto and Manual Focus |
| Focus Mode |
Automatic, Manual Focus |
Environmental
| Operating Temperature |
32.0 to 104.0°F / 0.0 to 40.0°C |
| Operating Humidity |
0 to 85% |
General
| Battery Type |
Canon BP-A Series |
| Power Consumption |
21.5 W |
| Tripod Mounting Thread |
1/4″-20 Female |
| 3/8″-16 Female |
| Accessory Mount |
1 x Cold Shoe Mount |
| 1 x Intelligent Hot Shoe |
| Built-In Video Light |
Yes (Infrared) |
| Dimensions (W x H x D) |
15.2 x 8.6 x 8.3″ / 385 x 219 x 210Â mm (With Protrusions) |
| 13.1 x 6.8 x 6.6″ / 333 x 173 x 168Â mm (Without Protrusions) |
| Weight |
4.4Â lb / 2010Â g |
