DARKÂ ROCK TF 2
No compromise silence and performance
Dark Rock TF 2 offers extreme cooling performance for the CPU and surrounding components as well as virtually inaudible operation.
- Immensely high cooling performance with 230W TDP
- 2 heat sinks with anti-vibration rubber inserts
- 6 high-performance 6mm heat pipes
- Silent Wings 3 135mm with funnel shaped air-inlet and a Silent Wings 135mm for virtually inaudible operation of max. 27.1dB(A)
- Optimized mounting system makes for an easy installation
- Special black coating with ceramic particles enables perfect heat transfer
- Brushed aluminum top cover for elegant look
- 3-year manufacturer’s warranty
- Product conception, design and quality control in Germany
EXTREME COOLING PERFORMANCE
Achieving an incredible performance-to-noise ratio
Thanks to its double-tower layout, this cooler is a true cooling marvel with 230W TDP – just perfect for the extreme conditions found in gaming PCs with overclocked CPUs that require a top flow cooler. Its design provides ideal cooling, not only for the CPU, but also for surrounding components.
VIRTUALLY INAUDIBLE OPERATION
Cooled by Silent Wings
With a funnel shaped Silent Wings 3 135mm as the upper fan, Dark Rock TF 2 provides highest cooling performance. A second Silent Wings fan takes care of airflow inbetween the 2 heat sinks. Both fans feature advanced fluid-dynamic bearings, smooth 6-pole motors and up to 9 airflow-optimized fan blades. The noise is a meager 27.1dB(A) even at 100% PWM fan speed. Anti-vibration rubber inserts on the cooling fins of the heat sink further dampen noise.
HIGH-PERFORMANCE HEAT PIPES
Ensuring perfect heat transfer
Dark Rock TF 2 has 6 high-performance copper heat pipes. They carry heat to the optimum locations on the cooling fins. The special black coating with ceramic particles enables a perfect transfer of heat.
INGENIOUS AND SPACE-SAVING DESIGN
Powerful cooling for your components
Dark Rock TF 2 contains 2 aluminum heat sinks that are arranged to save space for memory with a height of 49mm. It provides 2 fans out of the box, but a single fan assembly is also possible, offering further space savings and even quieter operation.
BRUSHED ALUMINUM COVER
For an unmistakable beefy look
The all-black design combined with the brushed aluminum cover gives this high-end cooler a touch of elegance and makes it look great in any system.
General data
| Model | Dark Rock TF 2 |
| TDP (W) | 230 |
| Color option | Black |
| Overall dimensions without mounting material (L x W x H), (mm) | 163 x 140 x 109 |
| Total weight (kg) | 0.95 |
| Socket compatibility Intel | 1700 / 1200 / 2066 / 1150 / 1151 / 1155 / 2011(-3) Square ILM |
| Socket compatibility AMD | AM5 / AM4 |
| Overall noise level (dB(A)) @ 50/75/100% (rpm) | 11.1 / 19.7 / 27.1 |
| Number of fans | 2 |
| Lighting connector | – |
Infographics
Heatsink specifications
| Dimensions (L x W x H), (mm) | 163 x 140 x 134 |
| Fin material | Aluminum |
| Surface treatment | Ceramic coating |
| Base material | Copper |
| CPU contact surface | CNC machined |
| Heatpipe number / Diameter (mm) | 6 / 6 |
| Decoupled fan mounting | ✓ |
Fan specifications
| Fan model | Silent Wings 3 135mm PWM / Silent Wings 135mm PWM |
| Fan dimensions (mm) | 135 x 135 x 25 / 135 x 135 x 22 |
| Speed @ 100%Â PWMÂ (rpm) | 1300 / 1400 |
| Airflow at 100% PWM / 12V (CFM / m3/h) | 60.0 / 101.9 | 86.3 / 146.6 |
| Air Pressure at 100% PWM / 12V (mm H2O) | 1.77 / 2.30 |
| Bearing technology | Fluid Dynamic Bearing |
| Motor technology | 6-pole fan motor |
| Rated Voltage (V) | 12 |
| Input current (A) | 0.40 / 0.40 |
| Safety current (A) | 0.40 / 0.40 |
| Input power (W) | 2.4 / 4.8 |
| Connector | 4-pin PWM |
| Lighting connector | – |
| Cable length (mm) | 220 |
| Lifespan (h / 25°C) | 300,000 |
| Y-Cable | – |
Accessories
| Thermal grease (Type) | Included |
| Mounting set | Intel & AMD |
| Screwdriver | – |
| Y-Cable | ✓ |
| User manual languages | CN, DE, EN, ES, FR, JP, PL, RU, TW |
Safety certification
| Approvals | CE, UL, TÃœV |
Environmental directives
| RoHS | ✓ |
| WEEE | ✓ |
| Triman | ✓ |
Logistics data and RRP
| Article number | BK031 |
| EAN code | 4260052188705 |
| Dimensions, package (L x W x H), (mm) | 210 x 190 x 230 |
| Gross weight, package (kg) | 1.6 |
| Pieces per packaging unit | 12 |
| Dimensions, shipping box (L x W x H), (mm) | 600 x 440 x 470 |
| Gross weight, shipping box (kg) | 21.0 |
