Dell Networking X1026P Smart Web Managed Switch, 24x 1GbE PoE (up to 12x PoE+) and 2x 1GbE SFP ports
Chassis | |||
X1008: | Dimensions (H x W x D): 1.67 in x 5.95 in x 5.95 in (42.5 mm x 151.13 mm x 151.13 mm) Rack mount: not available Unit weight: 0.80 Kg Fans: Fanless Design |
||
X1018: | Dimensions (H x W x D): 1.62 in x 8.23 in x 9.84 in (41.25 mm x 209.0 mm x 250.0 mm) Rack mount: 1RU, half width Unit weight: 1.76 Kg Fans: Fanless Design |
||
X1026: | Dimensions (H x W x D): 1.62 in x 8.23 in x 9.84 in (41.25 mm x 209.0 mm x 250.0 mm) Rack mount: 1RU, half width Unit weight: 1.88 Kg Fans: Fanless Design |
||
X1052: | Dimensions (H x W x D): 1.71 in x 17.1 in x 10.63 in (43.5 mm x 434.0 mm x 270.0 mm) Rack mount: 1RU Unit weight: 3.80 Kg Fans: 2 (rear) |
||
X4012: | Dimensions (H x W x D): 1.62 in x 8.23 in x 9.84 in (41.25 mm x 209.0 mm x 250.0 mm) Rack mount: 1RU, half width Unit weight: 2.03 Kg Fans: 2 (rear) |
||
Performance | |||
MAC addresses: 16K | Packet buffer memory: 1 Mb | ||
X1008: | Switch fabric capacity: Up to 16 Gbps Forwarding rate: 11.9 Mpps |
||
X1018: | Switch fabric capacity: Up to 36 Gbps Forwarding rate: 26.8 Mpps |
||
X1026: | Switch fabric capacity: Up to 52 Gbps Forwarding rate: 38.7 Mpps |
||
X1052: | Switch fabric capacity: Up to 176 Gbps Forwarding rate: 131 Mpps |
||
X4012: | Switch fabric capacity: Up to 240 Gbps Forwarding rate: 178.6 Mpps |
||
Power | |||
X1008: | Power supply: 24W (external) Power (max): 9.9W Power BTU/hr: 33.7 |
||
X1018: | Power supply: 40W Power (max): 14.7W Power BTU/hr: 50.2 |
||
X1026: | Power supply: 40W Power (max): 17.5W Power BTU/hr: 59.8 |
||
X1052: | Power supply: 100W Power (max): 60.2W Power BTU/hr: 205.2 |
||
X4012: | Power supply: 100W Power (max): 41.7W Power BTU/hr: 142.2 |
||
Management | Local password and restricted IP addresses for secure access to the switch Port mirroring provides the capability of mirroring 8 source ports and VLAN mirroring to improve network traffic monitoring and troubleshooting. | ||
VLAN | Supports up to 4096 port-based VLANs. Honors all 4096 VLAN tags. | ||
Quality of Service | Honor 802.1p values and honor IP DSCP values Supports strict priority and configurable weighted round robin (WRR) scheduling across queues |
||
Priority queues per port: | X1008: 4 X1018: 4 X1026: 4 X1052: 8 X4012: 8 |
