| Scanner type |
Sheetfed |
| Scan resolution, optical |
Up to 600 dpi (colour and monochrome, sheet-feed) |
| Scan resolution, hardware |
Up to 600 dpi (colour and monochrome, sheet-feed) |
| Duty cycle (daily) |
Recommended for 6000 pages per day |
| Bit depth |
24-bits external/48-bits internal |
| Automatic document feeder scan speed |
Up to 50 ppm/100 ipm (black & white, 300ppi) 1 |
| Scan speed OCR (A4) |
< 6 sec |
| Scan speed in preview mode |
Up to 6 sec |
| Task speed |
10 x 15 cm colour photo to file (200 dpi, 24-bit, tiff): about 5.18 sec for single image scan; 10 x 15 cm colour photo to email (150 dpi, 24-bit): about 4.98 sec for single image scan, about 1.43 sec for single image send to email, totally 6.41 sec; A4 PDF to email (300 dpi, 24-bit): about 6.63 sec for single image scan, about 3 sec for single image send to email, totally 9.63 sec |
| Scan size (ADF), maximum |
216 x 3100 mm |
| Scan size (ADF), minimum |
50.8 x 50.8 mm |
| Automatic document feeder capacity |
80 sheets |
| Scan file format |
For text and images: ePub 3.0, HTML 4.0, JPEG, Microsoft Excel/Powerpoint/Word, PDF, PNG, TIFF, Text (.txt), Rich Text (rtf), UNICODE Text, Windows Bitmap, WordPerfect, XML Document/Paper Specification and searchable PDF |
| Scan input modes |
Two scan modes (simplex/duplex) on front-panel for HP SDSS in Win OS and third parties applications via TWAIN, ISIS and WIA |
| Color scanning |
Yes |
| Levels of grayscale |
256 |
| Image scaling or enlargement range |
Will not perform any arbitrary scaling |
| Scan technology |
CMOS CIS |
| Output resolution dpi settings |
75; 100; 150; 200; 240; 300; 400; 500; 600; 1200 ppi |
| Document weight ADF (maximum) |
413 g/m² |
| Document weight ADF (minimum) |
40 g/m² |
| Media size (ADF) |
ISO A4: 210 x 297 mm; ISO A5: 148 x 210 mm; ISO A6: 105 x 148 mm; ISO A7: 74 x 104 mm; ISO A8: 52 x 74 mm; ISO B5: 176 x 250 mm; JIS B5: 182 x 257 mm |
| Media types |
Cut sheet paper, printed paper (laser and ink), pre-punched paper, bank checks, business cards, freight bills, carbonless forms, plastic carrier sheets for easily damaged documents, previously stapled media with staple removed, plastic cards (up to 1.24 mm) |
| Media weights, supported ADF |
40 to 413 g/m² |
| Scanner advanced features |
Auto colour detect; Auto crop; Auto exposure; Auto orientation; OCR; Zonal OCR; Zonal barcode; Edge removal; Background cleanup; Remove hole; Colour drop out; Straighten the page; Scan to cloud; Scan to email; PDF security; Misfeed detection advance setting; Advanced misfeed detection; Batch processing; Barcode; Scan to multiple destinations; Citrix Ready |
| Compatible Operating Systems |
OS X El Capitan 10.11, Microsoft® Windows® 10, 8.1, 8, 7, XP: 32/64-bit |
| Mac compatible |
No |
| Minimum System Requirements |
Microsoft® Windows® 10, 8.1, 8, 7, XP: 32/64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Microsoft® Internet Explorer |
| Twain version |
Windows: 32-bit and 64-bit TWAIN version 2.1; Mac: n/a |
| Processor speed |
550 MHz |
| Memory |
512 MB |
| Software included |
HP WIA Scan Driver, HP TWAIN Scan Driver (32/64-bit), HP Smart Document Scan Software, HP Scanner Tools Utility, I.R.I.S. Readiris Pro OCR, I.R.I.S. Cardiris, Nuance PaperPort, EMC ISIS driver |
| Connectivity, standard |
Hi-Speed USB 2.0 and USB 3.0 |
| Connectivity, optional |
USB 2.0 port for Wi-Fi accessory |
| Ports |
1 x USB 3.0 and 1 x USB 2.0 port |
| Power |
Input Voltage: 90 to 264 VAC, 50/60 Hz |
| Power supply type |
External Power Adapter |
| Power consumption |
4.4 watts (ready), 0.8 watts (sleep), 0.1 watts (off), 0.1 watts (auto-off) 2 |
| Control panel |
2-line 16 character per line LCD display, Simplex button, Duplex button, Cancel button, Power button with a LED and Tool button |
| Operating humidity range |
15 to 80% RH (non-condensing) |
| Recommended operating humidity range |
15 to 80% RH (non-condensing) |
| Non-Operating Humidity Range |
0 to 90% RH (non-condensing) |
| Operating temperature range |
10 to 35ºC |
| Recommended operating temperature range |
10 to 35ºC |
| Storage temperature range |
-40 to 60ºC |
| Acoustic power emissions (active, printing) |
0 to 90% RH (non-condensing) |
| Minimum dimensions (W x D x H) |
310 x 198 x 190 mm |
| Maximum dimensions (W x D x H) |
342 x 310 x 319 mm |
| Weight |
3.8 kg |
| Weight |
3.8 kg |
| Package dimensions (W x D x H) |
397 x 248 x 303 mm |
| Package weight |
5.4 kg |
| Ecolabels |
ENERGY STAR® 3.0 certified |
| Energy star certified |
Yes |
| Sustainable impact specifications |
RoHS compliance, HP GSE standard |
| Electromagnetic compatibility |
Class B Emissions; CISPR 22:2008 (International); European Union EMC Directive 2004/108/EC, EN 55022:2010 (CE mark); EAC EMC Certificate; Ukraine EMC approval; EN 61000-3-2:2014 (harmonics); EN 61000-3-3:2013 (flicker); Immunity CISPR 24:2010, EN 50024:2010 |
| Safety |
IEC 60950-1:2005 +A1 +A11 +A12 and all applicable amendments; CSA/UL 60950-1, 2nd edition (2007); EN 60950-1:2006 +A11 +A1 +A12 +A2; EAC safety; European Union CE; Kenya PVOC; Kuwait TER; Nigeria SON; Saudi Arabia SASO; South Africa NRCS; Ukraine safety approval |
| What’s in the box |
HP ScanJet Enterprise Flow 5000 s4 Sheet-feed Scanner; Installation guide; Support flyer; Warranty guide; 2 CDs; Power cord; USB cable; Power adapter |
| Manufacturer Warranty |
One-year bench commercial warranty whole unit replacement, phone and Web support included. Warranty may vary by country as required by law. Go to http://www.hp.com/support to learn about HP service and support options in your region. |
