NVIDIA RTX A2000 12GB
Compact Design. Unmatched Performance.
NVIDIA RTX A2000 12GB brings the power of RTX to more professionals with a powerful low-profile, dual-slot GPU design, delivering real-time ray tracing, AI-accelerated compute, and high-performance graphics to your desktop. The VR ready RTX A2000 12GB combines 26 second-generation RT Cores, 104 third-generation Tensor Cores, and 3,328 next-generation CUDA Cores and 12GB of GDDR6 graphics memory with error correction code (ECC) support, another industry first in this segment. Design bigger, render faster, work better, at previously unheard of price points with the NVIDIA RTX A2000 12GB.
With the introduction of the NVIDIA Ampere architecture, The next generation of NVIDIA RTX became available to millions of professionals. Featuring enhanced real-time ray tracing, accelerated AI, advanced graphics, and compute capabilities, the NVIDIA Ampere architecture gives artists, designers, engineers, and scientists the power to create tomorrow, today. With the overwhelming adoption of RTX technology, professionals are empowered to design, build, and entertain like never before since over 70 of the world’s leading design and creative applications are now accelerated by RTX technology.
Highlights
| GPU Architecture | NVIDIA Ampere |
| CUDA Cores | 3328 |
| Tensor Cores | 104 |
| RT Cores | 26 |
| Peak FP32 Performance | 8.0 TFLOPS |
| RT Core Performance | 15.6 TLOPS |
| Tensor Core Performance | 63.9 TFLOPS |
| GPU Memory | 12GB GDDR6 ECC |
| Memory Interface | 192-bit |
| Memory Bandwidth | 288 GB/s |
| Maximum Power Consumption | 70W |
| System Interface | PCI Express 4.0 x16 |
| Display Connectors | 4x mDP |
| Form Factor | 2.713″ H x 6.6″ Dual Slot |
| Thermal Solution | Active Fansink |
SPECIFICATIONS
Compatible in all systems that accept an NVIDIA RTX A2000 12GB
| Architecture | Ampere |
| Process Size | 8nm | Samsung |
| Transistors | 13.25 Billion |
| Die Size | 276mm2 |
| CUDA Cores | 3328 |
| Tensor Cores | 104 |
| RT Cores | 26 |
| Peak FP32 Performance | 8.0 TFLOPS |
| RT Core Performance | 15.6 TLOPS |
| Tensor Core Performance | 63.9 TFLOPS |
| GPU Memory | 12GB GDDR6 with ECC |
| GPU Memory Clock | 6001 MHz |
| Memory Inferface | 192-bit |
| Memory Bandwidth | 288 GB/s |
| Max Power Consumption | 70 W NVIDIA Quadro and RTX Power Guidelines |
| System Interface | PCI Express 4.0 x16 |
| Display Connectors | 4x mDP Latching |
| Form Factor | 2.713″ H x 6.6″ Low Profile | Dual Slot |
| Thermal Solution | Active Fansink |
| Max Digital Resolution | 2x 7680 x 4320 at 60 Hz |
| Max Displays | 4 NVIDIA RTX Display Resolution Support |
| HDR Support | Yes |
| AR | VR | XR Ready | Yes |
| Quad Buffered Stereo | Yes |
| Hardware Accelerated BVH | Yes |
| NVIDIA DLSS | Yes |
| NVIDIA Mosaic, Warp and Blend | Yes |
| NVIDIA RTX Experience | Yes |
| NVIDIA RTX Desktop Manager | Yes |
| NVIDIA Broadcast Application | Yes |
| NVENC | NVDEC | 1x H.264 and HVEC Encoders 1x Decode Engine |
AVAILABLE ACCESSORIES
- MDP-HDMI-FOUR-PCK connects the NVIDIA RTX A2000 12GB (or RTX A2000 6GB) to HDMI displays at resolutions up to 4K with PNY Part Number MDP-HDMI-FOUR-PCK. The four included DisplayPort to HDMI adapters are recommended by NVIDIA, provide outstanding image quality, and are built to professional standards.
- MDP-HDMI-SINGLE-PCK connects the NVIDIA RTX A2000 12GB (or RTX A2000) to an HDMI display at resolutions up to 4K with PNY Part Number MDP-HDMI-SINGLE-PCK. The included DisplayPort to HDMI adapter is recommended by NVIDIA, provides outstanding image quality, and is built to professional standards.
SUPPORTED OPERATING SYSTEMS
- Microsoft Windows 11 (64-bit)
- Microsoft Windows 10 (64-bit)
- Red Hat Enterprise Linux 7.x
- SUSE Linux Enterprise Desktop 15.x
- OpenSuse 15
- Fedora 31
- Ubuntu 18.04
- FreeBSD 11.x
- Solaris 11
MINIMUM SYSTEM HARDWARE REQUIREMENTS
- Intel Core i5, i7, i9, or Xeon processor or later
- AMD Ryzen or Epyc class processor or later
- PCI Express 4.0 x16 (preferred) expansion slot
- System memory greater than or equal to GPU memory, twice the GPU memory recommended
- Internet connection for driver installation
- DisplayPort 1.4a (preferred), HDMI, or DVI compatible display(s)
PACKAGE CONTAINS
- NVIDIA RTX A2000 12GB professional graphics card
- Attached low-profile (SFF) bracket
- Unattached full-height (ATX) bracket
