SILENT BASE 802
White
Excellent versatility, performance and silence
The be quiet! Silent Base 802 White is the perfect solution for sophisticated users who strive for whisper-quiet operation and maximum performance alike.
- Interchangeable top cover and front panel for either maximum airflow or silent operation
- 3 Pure Wings 2 140mm fans
- Extra thick insulation mats for improved noise reduction
- State-of-the-art I/O-panel with fan controller and USB 3.2 Gen. 2 Type C
- Decoupled motherboard tray can be relocated for an inverted layout
- Detachable top bracket ensures easy installation of radiators and fans
- Ready for radiators up to 420mm
INTERCHANGEABLE TOP COVER
Optimized for air or water cooling
The first of 2 included top covers perfectly rounds off the design of the Silent Base 802 White and ensures a silent operation. For all who strive for extremely powerful cooling and especially with water-cooled systems, the highly air-permeable top cover is the right choice.
INTERCHANGEABLE FRONTPANEL
Ensures maximum performance or whisper-quiet operationThe airflow front panel provides maximum performance for sophisticated configurations with highest demands for low temperatures. The standard front panel is the perfect choice for silent systems and regular PC configurations. Both panels are included.
THREE PREINSTALLED
PURE WINGS 2
Whisper-quiet operation
3 preinstalled Pure Wings 2 140mm fans with airflow-optimized fan blades ensure perfect airflow and solid cooling no matter if you chose a high airflow or a silence optimized configuration.
SUPERB NOISE DAMPENING
Extra thick insulation for maximum stability and silence
The front and sides are equipped with extra thick dampening mats of up to 10mm, resulting in maximum stability and superb noise dampening capabilities. The decoupled PSU bracket, motherboard tray and HDD cages also minimize vibrations. The full metal body provides stability for the case and improves its haptic.
SMART I/O PORT
State-of-the-art technology for your system
A USB 3.2 Gen. 2 Type C connector is provided on the front I/O port and allows usage of the latest hardware. The integrated 4-step fan controller allows the setting of the speed of up to 6 fans manually or connect all to one PWM signal.
VERSATILE MOTHERBOARD TRAY
Designed to fit individual requirementsThe motherboard tray is decoupled and can be installed alongside the left panel in an inverted layout. It is also removable for use as a test bench.
FUNCTIONAL PSU SHROUD
Offering a neat interiorThe PSU shroud perfectly covers the cables, PSU and contains a double HDD cage. The cover plates are separately detachable to install a 140mm fan on the top. With the small cover detached a 360mm or 420mm radiator can be installed at the front. Using the PSU bracket the power supply unit can be easily installed from behind.
General data
| Model | Silent Base 802 White |
| Color option | White |
| Motherboard compatibility | E-ATX (30.5 x 27.5cm) / ATX / M-ATX / Mini-ITX |
| Case size excl. stands (L x W x H), (mm) | 539 x 245 x 537 |
| Case size incl. stands (L x W x H), (mm) | 539 x 281 x 553 |
| Volume (l) | 70.91 |
| PSU form factor | ATX PS/2 |
| Net weight (kg) | 12.6 |
| Expansion slots | 7 + 2 |
Infographics
Pre-installed fans
| Fan at top | – |
| Fan at front | 2x Pure Wings 2 140mm |
| Fan at side | – |
| Fan at rear | 1x Pure Wings 2 140mm |
| Fan at bottom | – |
| Dimensions (L x W x H), (mm) | Front: 140 x 140 x 25 / Rear: 140 x 140 x 25 |
| Fan speed at 100% PWM / 12V (rpm) | 1000 |
| Airflow at 100% PWM / 12V (CFM / m3/h) | 61.2 / 104.0 |
| Air Pressure at 100% PWM / 12V (mm H2O) | 0.76 |
| Noise level at 100% PWM / 12V (dB(A)) | 18.8 |
| Voltage range (V DC) | 5 – 12 |
| Input power (W) | 1.4 |
| Input current (A) | 0.12 |
| Connector | 3-pin |
| Lifespan (h / 25°C) | 80,000 |
| Fan controller | 4-step fan controller (6x 3-pin) with PWM Hub |
Maximum fan installation
| Maximum fans | 8 |
| Top (mm) | 3x 120 / 3x 140 |
| Front (mm) | 3x 120 / 3x 140 |
| Side (mm) | – |
| Rear (mm) | 1x 140 |
| Bottom (mm) | – |
| PSU shroud | 1x 120 / 1x 140 |
Optional radiator installation
| Top (mm) | 120 / 240 / 360 |
| Front (mm) | 120 / 140 / 240 / 280 / 360 / 420 |
| Side (mm) | – |
| Rear (mm) | 120 / 140 |
| Bottom (mm) | – |
PSU compatibility
| Maximum dimensions excl. bottom fan (mm) | 288 |
| Maximum dimensions incl. bottom fan (mm) | 288 |
Graphics card
| HDD cage (in height of graphics card) installed (mm) | 287 |
| HDD cage (in height of graphics card) removed (mm) | 432 |
| Maximum PCIe slots with vertical graphics card (pcs.) | 2 |
Drive bay capacity
| 5.25 bays (pcs.) | – |
| 3.5 slots (scope of delivery) | 3 |
| 3.5 slots (max.) | 7 |
| 2.5 slots (scope of delivery) | 7 |
| 2.5 slots (max.) | 15 |
Cooling
| Max.construction height of CPU cooler unit (mm) | 185 |
| Airflow channel | Front / Top / Rear |
Lighting
| LED illumination | – |
| LEDs (pcs.) | – |
| LED type | – |
| LEDs synchronizable with controller/motherboard | – |
I/O Panel
| USB 3.2 Gen. 2 Type C | 1 |
| USB 3.2 Type A | 2 |
| USB 2.0 | – |
| HD Audio I/O | Mic + Audio |
| Qi charger / Quick Charging Option (W) | – |
Insulation and damping
| Top panel insulation mats | ✓ |
| Front panel insulation mats | ✓ |
| Side panel insulation mats | ✓ |
| Anti-vibration decoupled HDD | ✓ |
| Anti-vibration decoupled fan | ✓ |
| Anti-vibration decoupled PSU | ✓ |
| Anti-vibration decoupled motherboard-tray | ✓ |
Scope of delivery
| Screw set (Drives/Motherboard) | ✓ |
| Additional standoffs (pcs.) | 1 (for E-ATX) |
| SSD bracket for PSU shroud | – |
| LED strips (pcs.) | – |
| Cable ties (pcs.) | 6 (Velcro) |
| Screw box | – |
| VGA holder | – |
| VGA holder for inverted layout | – |
| Mesh Front Panel | ✓ |
| ODD Bracket | – |
| Fan / Radiator bracket for multi mounting panel | – |
Removeable dust filters
| Top | – |
| Front | 1 |
| Side | – |
| Bottom | 1 |
Material
| Top cover | ABS |
| Front panel | ABS |
| Side panel | Steel |
| Side panel window | – |
| Stands | ABS |
Safety certification
| Approvals | CE, UKCA |
Environmental directives
| RoHS | ✓ |
| Reach | ✓ |
| WEEE | – |
| Triman | ✓ |
Logistics data and RRP
| Article number | BG040 |
| EAN code | 4260052188392 |
| Dimensions, package (L x W x H), (mm) | 651 x 323 x 615 |
| Gross weight, package (kg) | 13.34 |
| Pieces per packaging unit | 1 |
