Sony PXW-FX9 XDCAM 6K Full-Frame Camera System body
Sony PXW-FX9 XDCAM 6K Full-Frame Camera System body
- 6K Full-Frame Exmor R CMOS Sensor
- 15 Stops of Dynamic Range, Dynamic HDR
- DCI 4K and UHD 4K up to 60p
- Quad Full HD 120p Raw with XDCA-FX9 Unit
- HD Recording up to 150/180 fps
- Sony E-Mount
- 10-Bit 4:2:2 XAVC-I up to 600 Mb/s
- Auto-HD, AF, 7-Stop ND Filter, 3D LUTs
- Dual Base ISO up to 102,400, HLG Mode
- 12G/6G/3G-SDI & HDMI Output up to 4K
Description
Sony PXW-FX9 XDCAM 6K Full-Frame Camera System body
Specifications:
Imaging
| Lens Mount | Sony E |
| Lens Communication | Yes, with Autofocus Support |
| Sensor Resolution | Actual: 20.5 Megapixel |
| Effective: 19 Megapixel | |
| Image Sensor | 35.7 x 18.8 mm (Full-Frame) CMOS |
| Image Stabilization | Supplies Stabilization Metadata |
| Built-In ND Filter | Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters and a 2 to 7 Stop Electronic ND Filter |
| Internal Filter Holder | No |
| Capture Type | Video Only |
Exposure Control
| Shutter Type | Electronic Rolling Shutter |
| Shutter Speed | 1/8000 to 1 Second |
| ISO Sensitivity | 800 to 4000 (Extended: 320 to 102,400) |
| Gain | -3 to 18 dB |
| Shutter Angle | 5.6 to 360° |
| Advertised Dynamic Range | 15 Stops |
| Signal-to-Noise Ratio | 57 dB |
| White Balance | 2000 to 15,000K |
Video Capture
| Internal Recording Modes | XAVC-I 4:2:2 10-Bit |
| 4096 x 2160 at 23.98/25/29.97/50/59.94 fps | |
| 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [240 to 600 Mb/s] | |
| 1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps [89 to 222 Mb/s] | |
| 1920 x 1080i at 50/59.94 fps [112 Mb/s] | |
| XAVC-L 4:2:2 10-Bit | |
| 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 150 Mb/s] | |
| 1920 x 1080p at 23.98/25/29.97/100/120 fps [25 to 50 Mb/s] | |
| 1920 x 1080i at 50/59.94 fps [50 Mb/s] | |
| MPEG HD422 4:2:2 10-Bit | |
| 1920 x 1080p at 23.98/25/29.97 fps [50 Mb/s] | |
| 1920 x 1080i at 50/59.94 fps [50 Mb/s] | |
| XAVC Proxy 4:2:0 10-Bit | |
| 1920 x 1080 [9 Mb/s] | |
| 1280 x 720 [6 to 9 Mb/s] | |
| 640 x 360 [3 Mb/s] | |
| External Recording Modes | Raw 16-Bit via Proprietary Module |
| 4096 x 2160 from 1 to 59.94 fps | |
| 3840 x 2160 from 1 to 59.94/100/120 fps | |
| 2048 x 1080 at 59.94/100/120/150/180 fps | |
| Sensor Crop Modes | Super35 / APS-C |
| Fast-/Slow-Motion Support | Yes |
| Gamma Curve | HDR-HLG, S Cinetone, Sony S-Log 3, Standard |
| Built-In Microphone Type | Mono |
| Audio Recording | XAVC: 4-Channel 24-Bit 48 kHz LPCM Audio |
| Proxy: 2-Channel AAC Audio | |
| IP Streaming | Yes |
Interface
| Media/Memory Card Slot | Slot 1: XQD |
| Slot 2: XQD | |
| Dual Slot: SD/SDHC/SDXC/Memory Stick Duo Hybrid | |
| Video I/O | 1 x BNC (12G-SDI) Output |
| 1 x BNC (3G-SDI) Output | |
| 1 x HDMI 2.0 Output | |
| Audio I/O | 2 x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input |
| 1 x 1/8″ / 3.5 mm TRS Stereo Headphone Output | |
| Power I/O | 1 x Barrel (18 to 20.5VDC) Input |
| Other I/O | 1 x BNC (Genlock) Data Input |
| 1 x BNC (Timecode) Data Input/Output | |
| 1 x 2.5 mm Sub-Mini (LANC) Control | |
| 1 x Micro-USB (USB 3.2 / 3.1 Gen 1) Data | |
| Wireless | 2.4 / 5 GHz Wi-Fi 5 (802.11ac) |
| Mobile App Compatible | Yes |
| Global Positioning (GPS, GLONASS, etc.) | None |
Display
| Size | 3.5″ |
| Resolution | 2,760,000 Dot |
| Display Type | Included External Touchscreen LCD |
Viewfinder
| Type | Optional, Not Included |
Focus
| Focus Type | Auto and Manual Focus |
| Focus Mode | Automatic, Manual Focus |
General
| Battery Type | Sony BP-U Series |
| Power Consumption | 35.2 W |
| Tripod Mounting Thread | 3/8″-16 Female (Bottom) |
| 1/4″-20 Female (Bottom) | |
| Accessory Mount | 1 x Intelligent Hot Shoe |
| 1 x Cold Shoe Mount | |
| 2 x 3/8″-16 Female | |
| 6 x 1/4″-20 Female | |
| Netflix Approved | Yes |
| Material of Construction | Magnesium Alloy |
| Dimensions (W x H x D) | 5.7 x 5.6 x 9″ / 146 x 142.5 x 229Â mm (Without Protrusions) |
| Weight | 10.58 lb / 4.8 kg (With Battery, Grip, Handle, Monitor, Recording Media, Viewfinder) |
| 4.41Â lb / 2.00Â kg (Body Only) |
