Canon EOS 90D DSLR Camera Body Only

Featuring an impressively high-resolution 32.5MP APS-C CMOS sensor, the 90D is capable of producing imagery with notable clarity and dynamic range, as well as a broad sensitivity range of ISO 100-25600 and low noise to support working in difficult lighting situations. The sensor and image processor also realize fast performance throughout the camera system, including the ability to shoot continuously at up to 10 fps, record UHD 4K30p video, or record high-speed Full HD 1080p video at 120 fps.

Benefitting stills shooting with the optical viewfinder, a wide-area 45-point all cross-type phase-detection autofocus system provides quick and precise focusing in difficult lighting conditions down to -3 EV. For working with telephoto lenses fitted with extenders, 27 of the points are capable of focusing down to f/8 and the center dual cross-type offers increased precision at brighter aperture values. The cross-type design of the sensors affords greater accuracy in low-contrast and mixed lighting conditions, and the broad coverage of the 45 sensors is ideal for tracking and maintaining focus on moving subjects. Making use of the 45-points is a series of four AF area selection modes, including single-point AF; Zone AF, where you can select from one of nine AF zones; Large Zone AF, which offers a choice of three selectable zones; and 45-point AF auto selection, which allows the camera to select a single point automatically.

When recording video or shooting in live view, a Dual Pixel CMOS AF system is employed that features 5481 selectable autofocus points. This focusing system offers smooth and fast focusing performance in a similar manner to how a camcorder acquires focus. Dual Pixel CMOS AF integrates two separate photodiodes within each pixel to provide a broad and dense network of phase-detection gathering elements across a majority of the image sensor to reduce focus hunting for faster, more direct control of focus placement. When working with still imagery, this focusing system works to acquire focus quickly and accurately, making it ideally suited to shooting and tracking moving subjects so that critical focus is attained with each shot. When shooting video, a Movie Servo AF mode offers smooth and natural focusing when changing from different subjects or different distances within the scene, as well as the ability to specify tracking sensitivity, AF speed, and Face Tracking priority. Benefited by the Touch AF system, rack focus is possible simply by touching elements within the scene on the touchscreen in order to change focus in an intuitive manner. Subject tracking in movies is also heightened due to the Dual Pixel CMOS AF system’s ability to recognize subjects and maintain focus when working within changing or cluttered scenery.

• Touchscreen 3.0″ 1.04m-dot LCD monitor features a vari-angle design to permit working from high and low angles and the touchscreen design facilitates intuitive control over menu navigation and touch-to-focus operation.
• The pentaprism-type optical viewfinder offers 100% frame coverage for high compositional accuracy when shooting at eye level. Additionally, further aiding shooting with the viewfinder, AF points and mode, compositional grids, a horizontal electronic level, and other assistive features can be displayed during use.
• Included LP-E6N battery provides approximately 1300 shots per charge.
• Built-in Wi-Fi allows for easy wireless sharing of both photos and movies to a linked mobile device and Bluetooth connectivity permits linking a smartphone or tablet for quick image sharing between devices as well as remote control capabilities when using the Canon Camera Connect app. This app also enables a mobile raw-editing workflow for greater post-production freedom.

• In-camera 4K time-lapses can be produced, along with 4K frame grabs for effectively shooting 8MP stills at up to 30 fps.
• A revised 220000-pixel AE metering sensor benefits both autofocus and exposure metering precision and enables Color Tracking for more accurately detecting skin colors.
• EOS iTR autofocus provides face detection for refined focus control when shooting portraits.
• The electronic shutter function permits working with shutter speeds up to 1/16000 of a second.

Specifications:

Imaging

Lens Mount	Canon EF-S
Sensor Resolution	Actual: 34.4 Megapixel
	Effective: 32.5 Megapixel (6960 x 4640)
Image Sensor	22.3 x 14.8 mm (APS-C) CMOS
Crop Factor	1.6x
Image Stabilization	Digital (Video Only)
Mirror Lock-Up	Yes
Capture Type	Stills & Video

Exposure Control

Shutter Type	Electronic Shutter, Mechanical Focal Plane Shutter
Shutter Speed	Mechanical Shutter
	1/8000 to 30 Seconds
	Electronic Shutter
	1/16000 to 30 Seconds
Bulb/Time Mode	Bulb Mode
ISO Sensitivity	Photo/Video
	100 to 25,600 in Auto Mode (Extended: 100 to 51,200)
Metering Method	Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes	Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation	-5 to +5 EV (1/3, 1/2 EV Steps)
Metering Range	1 to 20 EV
White Balance	Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
Continuous Shooting	Up to 10 fps at 32.5 MP for up to 25 Frames (Raw) / 58 Frames (JPEG)
	Up to 11 fps at 32.5 MP
	Up to 7 fps at 32.5 MP
Interval Recording	Yes
Self-Timer	2/10-Second Delay

Still Image Capture

Image Sizes	16:9 Raw
	6960 x 3904
	4:3 Raw
	6160 x 4640
	3:2 Raw
	6960 x 4640
	1:1 Raw
	4640 x 4640
	16:9 JPEG
	6960 x 3904
	4800 x 2688
	3472 x 2952
	2400 x 1344
	4:3 JPEG
	6160 x 4640
	4256 x 3200
	3072 x 2320
	2112 x 1600
	3:2 JPEG
	6960 x 4640
	4800 x 3200
	3472 x 2320
	2400 x 1600
	1:1 JPEG
	4640 x 4640
	3200 x 3200
	2300 x 2300
	1600 x 1600
Aspect Ratio	1:1, 3:2, 4:3, 16:9
Image File Format	JPEG, Raw
Bit Depth	14-Bit

Video Capture

Internal Recording Modes	H.264/MP4
	UHD 4K (3840 x 2160) at 23.98/25/29.97 fps
	1920 x 1080p at 23.98/25/29.97/50/59.94/100 fps
	1280 x 720 at 50/59.94 fps
External Recording Modes	4:2:2 8-Bit via HDMI
	UHD 4K (3840 x 2160) up to 25/29.97 fps
Recording Limit	Up to 30 Minutes
Broadcast Output	NTSC
IP Streaming	None
Built-In Microphone Type	Stereo
Audio Recording	AAC Audio

Interface

Media/Memory Card Slot	Single Slot: SD/SDHC/SDXC (UHS-II)
Video I/O	1 x Mini-HDMI Output
Audio I/O	1 x 1/8″ / 3.5 mm TRS Stereo Headphone Output
	1 x 1/8″ / 3.5 mm TRS Stereo Microphone Input
Power I/O	None
Other I/O	1 x Micro-USB (USB 2.0) Data Output
	1 x Canon E3 (2.5 mm Sub-Mini) Input
Wireless	Wi-Fi, Bluetooth
Mobile App Compatible	Yes
	*As of August, 2019: Check with manufacturer for the most up-to-date compatibility
Global Positioning (GPS, GLONASS, etc.)	None

Display

Size	3.0″
Resolution	1,040,000 Dot
Display Type	Articulating Touchscreen LCD
Secondary Display	Top: Status Display

Viewfinder

Type	Optical (Pentaprism)
Eye Point	22 mm
Coverage	100%
Magnification	Approx. 0.95x
Diopter Adjustment	-3 to +1

Focus

Focus Type	Auto and Manual Focus
Focus Mode	Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points	Phase Detection: 45 (45 Cross-Type)
	Phase Detection: 5481
Autofocus Sensitivity	-3 to +18 EV

Flash

Built-In Flash	Yes
Flash Modes	Auto, Manual
Guide Number	39.37′ / 12 m at ISO 100
Maximum Sync Speed	1/250 Second
Flash Compensation	-3 to +3 EV (1/3, 1/2 EV Steps)
Dedicated Flash System	eTTL
External Flash Connection	Hot Shoe

Environmental

Operating Temperature	32 to 72°F / 0 to 40°C
Operating Humidity	0 to 85%

General

Battery Type	1 x LP-E6N Rechargeable Lithium-Ion, 7.2 VDC, 1865 mAh (Approx. 1300 Shots)
Tripod Mounting Thread	1 x 1/4″-20 Female (Bottom)
Accessory Mount	1 x Hot Shoe Mount
Material of Construction	Magnesium Alloy, Polycarbonate
Dimensions (W x H x D)	5.54 x 4.13 x 3.02″ / 140.7 x 104.8 x 76.8 mm
Weight	1.54 lb / 701 g (Body Only)
