Canon EOS R10 RF-S18-45mm f/4.5-6.3 IS STM kit
EOS R10: Compact and Capable, for Content Creators
Emphasizing portability without sacrificing on capability, the Canon EOS R10 is a sleek mirrorless camera with a hybrid ethos. Adept in both photo and video worlds, the R10 brings an APS-C sensor to the R system, along with high-speed shooting, intelligent AF, and impressive 4K video recording to complement a multimedia workflow.
Specifications:
Imaging
| Lens Mount | Canon RF |
| Sensor Resolution | Actual: 25.5 Megapixel |
| Effective: 24.2 Megapixel | |
| Image Sensor | 22.3 x 14.9 mm (APS-C) CMOS |
| Crop Factor | 1.6x |
| Image Stabilization | Digital (Video Only) |
| Built-In ND Filter | None |
| Capture Type | Stills & Video |
Exposure Control
| Shutter Type | Electronic Shutter, Mechanical Focal Plane Shutter |
| Shutter Speed | Mechanical Shutter |
| 1/4000 to 30Â Seconds | |
| Electronic Shutter | |
| 1/4000 to 30Â Seconds | |
| Bulb/Time Mode | Bulb Mode |
| ISO Sensitivity | Photo |
| 100 to 32,000 in Manual, Auto Mode (Extended: 100 to 51,200) | |
| Metering Method | Center-Weighted Average, Evaluative, Partial, Spot |
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
| Exposure Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Metering Range | -2 to 20 EV |
| White Balance | Presets:Â Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten |
| Continuous Shooting | Electronic Shutter |
| Up to 23 fps at 24.2 MP for up to 70 Frames (JPEG) / 21 Frames (Raw) | |
| Mechanical Shutter | |
| Up to 15 fps at 24.2 MP for up to 460 Frames (JPEG) / 29 Frames (Raw) | |
| Interval Recording | Yes |
| Self-Timer | 2/10-Second Delay |
Still Image Capture
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
| Image File Format | C-RAW, HEIF, JPEG, Raw |
Video Capture
| Internal Recording Modes | H.264/MP4 4:2:0 8-Bit |
| UHD 4K (3840 x 2160) at 23.98/25/29.97/59.94 fps | |
| 1920 x 1080p at 23.98/25/29.97/50/59.94/100 fps | |
| H.265/MP4 4:2:2 10-Bit | |
| UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps | |
| 1920 x 1080p at 23.98/25/29.97/50/59.94/100 fps | |
| Gamma Curve | HDR-PQ |
| Broadcast Output | NTSC/PAL |
| IP Streaming | Yes |
| Built-In Microphone Type | Stereo |
| Audio Recording | MP4: 2-Channel AAC Audio |
Interface
| Media/Memory Card Slot | Single Slot: SD/SDHC/SDXC (UHS-II) |
| Video I/O | 1 x Micro-HDMI Output |
| Audio I/O | 1 x 1/8″ / 3.5 mm TRS Stereo Microphone Input |
| Other I/O | 1 x USB-C (USB 2.0) Input/Output |
| 1 x 2.5 mm Sub-Mini Control | |
| Wireless | 2.4 GHz Wi-Fi (802.11b/g) |
| Bluetooth | |
| Global Positioning (GPS, GLONASS, etc.) | None |
Display
| Size | 3.0″ |
| Resolution | 1,040,000 Dot |
| Display Type | Free-Angle Tilting Touchscreen LCD |
Viewfinder
| Type | Built-In Electronic (OLED) |
| Resolution | 2,360,000 Dot |
| Eye Point | 22 mm |
| Coverage | 100% |
| Magnification | Approx. 0.95x |
| Diopter Adjustment | -3 to +1 |
Focus
| Focus Type | Auto and Manual Focus |
| Focus Mode | Continuous-Servo AF, Manual Focus, Single-Servo AF |
| Autofocus Points | Photo, Video |
| Phase Detection: 651 | |
| Autofocus Sensitivity | -4 to +20 EV |
Flash
| Built-In Flash | Yes |
| Guide Number | 19.7′ / 6Â m at ISO 100 |
| Maximum Sync Speed | 1/250 Second |
| Flash Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Dedicated Flash System | eTTL |
| External Flash Connection | Intelligent Hot Shoe |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 85% |
General
| Battery Type | 1 x LP-E17 Rechargeable Lithium-Ion |
| Tripod Mounting Thread | 1 x 1/4″-20 Female (Bottom) |
| Dimensions (W x H x D) | 4.8 x 3.5 x 3.3″ / 122.5 x 87.8 x 83.4Â mm |
| Weight | 13.5Â oz / 382.2Â g (Body Only) |
| 15.1 oz / 429.2 g (With Battery, Recording Media) |
Canon RF-S 18-45mm F/4.5-6.3 IS STM Lens Specifications
Physical
| Focal Length | 18 to 45mm (35mm Equivalent Focal Length: 29 to 72mm) |
| Maximum Aperture | f/4.5 to 6.3 |
| Minimum Aperture | f/32 |
| Lens Mount | Canon RF |
| Lens Format Coverage | APS-C |
| Angle of View | 74° 20′ to 33° 40′ |
| Minimum Focus Distance | 7.9″ / 20Â cm |
| Maximum Magnification | 0.16x |
| Optical Design | 7 Elements in 7 Groups |
| Diaphragm Blades | 7, Rounded |
| Focus Type | Autofocus |
| Image Stabilization | Yes |
| Filter Size | 49 mm (Front) |
| Dimensions (ø x L) | 2.7 x 1.7″ / 68.9 x 44.3 mm |
| Weight | 4.6Â oz / 130Â g |
