Canon IR-2425 Photocopier
Machine Type | A3 Monochrome Laser Multifunctional |
Core Functions | Print, Copy, Scan, Send, and Optional Fax |
Control Panel | 7 inch TFT LCD WVGA color Touch panel |
Memory | Standard: 2.0GB RAM |
Storage | Use area: 30GB (eMMC) |
Interface Connection | NETWORK Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)OTHERS Standard: USB 2.0 (Host) x3, USB 2.0 (Device) x1 |
Paper Supply Capacity (A4, 80gsm) | Standard: 330 sheets Maximum: 580 sheets (with Cassette Feeding Module-AK1) |
Paper Output Capacity (A4, 80 gsm) | Standard: 250 sheets Maximum: 250 sheets |
Finishing Capabilities | Standard model: Collate, Group |
Supported Media Types | Multi-purpose Tray: Thin, Plain, Recycled, Color, Heavy, Bond, Transparency, Label, Pre-punched, EnvelopePaper Cassette: Plain, Recycled, Color, Pre-punched |
Supported Media Sizes | Multi-purpose tray: Standard size: A3, A4, A4R, A5, A5R, B4, B5, B5R, Envelopes [No. 10(COM 10), Monarch, ISO-C5, DL] Custom Size/Free Size: Min.95.0 x139.7 mm up to 297.0 x431.8 mmPaper Cassette: Standard size: A3, A4, A4R, A5R, B4, B5, B5R |
Supported Media Weights | Multi-purpose tray: 60 to 157 gsm Paper Cassettes: 64 to 90 gsm Duplex: 60 to 90 gsm |
Warm-up Time (Quickstart mode: ON) |
4 Seconds or Less*1 From Sleep Mode: 10 seconds or less 12 Seconds or Less*2 |
Dimensions (W x D x H) | With Platen Cover-AA1: 627 x 665 x 516 mm With DADF-AZ2: 627 x 692 x 616 mm |
Installation Space (W x D) | 1065 x 1285 mm |
Weight | With Platen Cover-AA1: Approx. 34.9 kg including toner With DADF-AZ2: Approx. 39.9 kg including toner |
Print Speed (ppm) | Up to 25 ppm (A4), Up to 12 ppm (A3), Up to 11 ppm (A4R) |
Print Resolution (dpi) | 600 x 600 |
Page Description Languages | Standard: UFRII Optional: PCL6, Adobe®PostScript®3™ |
Direct Print | Supported file types: RUI: PDF, EPS, TIFF/JPEG, XPS USB Memory: PDF, TIFF/JPEG, XPS Network Place: PDF, TIFF/JPEG, XPS |
Printing from Mobile and Cloud | AirPrint, Mopria, Google Cloud Print, Canon Business PRINT, and uniFLOW Online |
Fonts | PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T*3 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*4 PS fonts: 136 Roman |
Print Features | Secure Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/Orientations, Toner Reduction, Poster Printing, Forced hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer |
Operating System | UFRII: Windows® 7 / 8.1 / 10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016 / Server 2019, MAC OS X (10.10 or later) PCL: Windows® 7 / 8.1 / 10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016 / Server 2019 PS: Windows® 7 / 8.1 / 10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016 / Server 2019, MAC OS X (10.10 or later) PPD: Windows® 7 / 8.1 / 10, MAC OS X (10.10 or later) |
Copy | |
Copy Speed (BW) | Up to 25 ppm (A4), up to 12 ppm (A3), up to 11 ppm (A4R) |
First-Copy-Out Time (A4) (BW) | Approx. 7.4 seconds or less |
Copy Resolution (dpi) | 600 × 600 |
Multiple Copies | Up to 9,999 copies |
Copy Density | Automatic or Manual (9 Levels) |
Magnification | 25% – 400% (1% Increments) Preset reduction/enlargement: 25%, 50%, 61%, 70%, 81%, 86%, 100%, 115%, 122%, 141%, 200%, 400% |
Copy Features | Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Sort, Job Build, N on 1, Different Size Originals, Sharpness, Erase Frame, Gutter, Copy ID Card, Free Size Original, Reserved copy, Copy Sample |
Scan | |
Type | Optional: Duplexing Automatic Document Feeder [2-sided to 2-sided] (DADF-AZ2) or Platen Cover (Platen Cover-AA1) |
Document Feeder Paper Capacity (80 gsm) | DADF-AZ2: 50 Sheets |
Acceptable Originals and Weights | Platen: Sheet, Book Document Feeder media weight: 1-sided scanning: 37 to 128 gsm (BW/CL) 2-sided scanning: 52 to 128 gsm (BW/CL) Only 1-sheet feeding is supported in 37-52 and 105-128 gsm. |
Supported Media Sizes | Platen: Max. scanning size: 297.0 x 432.0 mm Document Feeder media size: A3, A4, A4R, A5, A5R, B4, B5, B5R Custom size: 139.7 x 148.5 mm to 297.0 x 432.0 mm |
Scan Speed (ipm: BW/CL; A4) | DADF-AZ2: 1-sided Scanning: 35/25 (300 dpi, send), 25/13 (600 dpi, copy) 2-sided Scanning: 12/8 (300 dpi, send), 8/4 (600 dpi, copy) |
Scan Resolution (dpi) | Scan for Copy: up to 600 x 600 Scan for Send: (Push,BW) up to 600 x 600, (Pull,BW) up to 600 x 600 (Push,CL) up to 300 x 300, (Pull,CL) up to 300 x 300 Scan for Fax: up to 600 x 600 |
Pull Scan Specifications | Color Network ScanGear2. For both TWAIN and WIA Supported OS: Windows® 7/8.1/10 Windows® Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016 |
Scan Method | Push scan, Pull scan, Scan to Network, Scan to memory media (USB Memory Key), Scan to Mobile Devices, Scan to cloud-based services (uniFLOW) |
Send | |
Destination | Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP WebDAV Optional: Super G3 FAX |
Address Book | LDAP (2,000)/Local (1,600)/Speed dial (200) |
Send Resolution (dpi) | Push: 100 x 100, 150 x 150, 200 x 100 (Standard), 200 x 200 (Fine), 200 x 400*5 (SuperFine), 300 x 300, 400 x 400*5 (UltraFine), 600 x 600*5 Pull: 75 x 75, 100 x 100, 150 x 150, 200 x 200, 300 x 300, 400 x 400*5, 600 x 600*5 |
Communication Protocol | File: FTP (TCP/IP), SMB (TCP/IP), WebDAV Email/iFax: SMTP (send), POP3 (receive) |
File Format | Standard: TIFF (MMR), JPEG*6, PDF (Compact, PDF/A-1b, Encrypted), XPS (Compact), PDF/XPS (Device Signature) Optional: PDF (Trace & Smooth), PDF/XPS (User Signature), PDF/XPS (Searchable), Office Open XML (PowerPoint, Word) |
Universal Send Features | Original Type Selection, Two-sided Original, Different-size Originals, Density Adjustment, Sharpness, Erase Frame, Job Build, Sender’s Name (TTI), Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation |
Fax | |
Maximum Number of Connection Lines | 1 |
Modem Speed | Super G3: 33.6 kbps G3: 14.4 kbps |
Compression Method | MH, MR, MMR, JBIG |
Resolution (dpi) | 400 x 400 (Ultrafine), 200 x 400 (Superfine), 200 x 200 (Fine/Photo), 200 x 100 (Normal) |
Sending / Receiving Size | Sending: A3, A4, A4R, A5*8, A5R*8, B4, B5*7, B5R*8 Receiving: A3, A4, A4R, A5R, B4, B5, B5R |
FAX / Memory | Up to 30,000 pages |
Speed Dials | Max. 200 |
Group Dials / Destinations | Max. 199 dials |
Sequential Broadcast | Max. 256 addresses |
Memory Backup | Yes |
Fax Features | Sender’s Name (TTI), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, TX Reservation, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox |
Security | |
Authentication and Access Control | User Authentication (Picture Login, Picture and PIN Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online Express (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Log-in), Access Management System (Access Control) |
Document | Print Security (Secure Print, Encrypted SecurePrint, Forced Hold Printing, uniFLOW Secure Print*9), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS*10), Send Data Security (Confirming FAX number, Allow/Restrict Fax Driver Transmissions, S/MIME Support) |
Network | TLS, IPSec, IEEE802.1X authentication, SNMPv3, Firewall Functionality(IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Scan and Send -Virus Concerns for E-mail Reception) |
Device | Standard Storage Initialize, Protecting MFP Software Integrity, Verify System at Startup |
Device Management and Auditing | Administrator Password, Digital Certificate, and Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Security Policy Setting |
Environmental | |
Operating Environment | Temperature: 10 to 30ºC Humidity: 20 to 80 % RH (Relative Humidity) |
Power Source | 220-240V 50/60Hz 2.7A |
Power Consumption | Maximum: Approx. 1,500 W Standby: Approx. 22.1 W*11 Sleep Mode: Approx. 1 W*12, Approx. 2 W*13 |
Consumables | |
Toner Cartridge/s | NPG-59 Black Toner |
Toner (Estimated Yield @ 6% Coverage) | Black: 10,200 impressions (A4) |
Software and Printer Management | |
Tracking and Reporting | uniFLOW Online Express |
Remote Management Tools | iW Management Console eMaintenance Content Delivery System |
Scanning software | ScanGear |
Optimization Tools | Canon Driver Configuration Tool |
Document Publishing | iW Desktop |
Paper Supply Options | |
Cassette Feeding Module-AK1 | Cassette Feeding Module-AK1 Paper Capacity: 250 sheets (80gsm) Paper Type: Plain, Recycled, Color, Pre-punched Paper Size: A3, A4, A4R, A5, B4, B5, B5R Custom Size: – Paper Weight: 64 to 90 gsm Power Source: Main Unit Dimensions (W x D x H): 581 x 575 x 92 mm Weight: Approx. 5.8kg |
Hardware Accessories | |
Others | DADF-AZ2 Platen Cover-AA1 |
System and Controller Options | |
Print Accessories | PCL International Font Set-A1 PS Printer Kit-CM1 PCL Printer Kit-CM1 |
Send Options | Universal Send Digital User Signature Kit-C1 Universal Send Advanced Feature Set-H1 |
Barcode Printing | Barcode Printing Kit-D1 |
System Accessories | Copy Control Interface Kit-D1 |
Fax Accessories | Super G3 FAX Board-BE1 Remote Fax Kit-A1 |
Time from device power-on to when key operations can be performed on the touch panel display. | |
Time from device power-on, until copy ready (not print reservation). | |
Requires optional PCL International Font Set-A1. | |
Requires optional Barcode Printing Kit-D1. | |
Color mode is black and white only. | |
Single page only. | |
Sent as B4. | |
Sent as A4. | |
Requires optional uniFLOW Online / uniFLOW. | |
Requires optional Universal Send Digital User Signature Kit-C1. | |
Reference value: measured one unit. | |
Wireless LAN power serve mode OFF. Sleep mode is not available in all circumstances due to certain settings. | |
Wireless LAN power serve mode ON. Sleep mode is not available in all circumstances due to certain settings. |
