DJI Osmo Mobile 6 Smartphone Gimbal Stabilizer Specifications
Gimbal
| Load Capacity | 6 to 10.2Â oz / 170 to 290Â g |
| Number of Axes | 3-Axis (Pitch (Tilt), Roll, Yaw (Pan)) |
| Rotation Range | Mechanical Range |
| Yaw (Pan): 335.4° (-161.6 to 173.8°) | |
| Pitch (Tilt): 180.2° (-101.6 to 78.6°) | |
| Roll: 332.3° (-120.3 to 212°) | |
| Controllable Range | |
| Yaw (Pan): 190° (-95 to 95°) | |
| Pitch (Tilt): 65° (-25 to 40°) | |
| Roll: 275° (-100 to 175°) | |
| Follow Speed | Pan: 120°/s |
| Tilt: 120°/s | |
| Roll: 120°/s |
Compatibility
| Camera Control | On Compatible Models |
| Smartphone Dimensions | Width: 2.64 to 3.31″ / 67 to 84Â mm |
| Thickness: 0.3 to 0.4″ / 6.9 to 10Â mm |
Connectivity
| Inputs/Outputs | 1 x USB-C (5 VDC Power) Input |
| Wireless Protocol | Bluetooth 5.0 |
Battery
| Battery Type | 1 x Built-In |
| Battery Capacity | 1000 mAh / 7.74 Wh |
| Battery Runtime | 6.4 Hours |
| Battery Charging Time | 1.5 Hours |
| Battery Chemistry | Lithium-Ion |
General
| Display Type | None |
| Mounting | 1 x 1/4″-20 Female |
| Dimensions | 7.4 x 3.3 x 3.9″ / 189 x 84.5 x 99Â mm (Folded) |
| 10.9 x 4.4 x 3.9″ / 276 x 111.5 x 99Â mm | |
| Weight | 10.9Â oz / 309Â g |
