Canon EOS R6 body

Canon EOS R6 body

Image Sensor

• Type
  35.9 x 23.9 mm CMOS
• Effective Pixels
  Approx. 20.1 megapixels
• Total Pixels
  Approx. 21.4 megapixels
• Aspect Ratio
  3:2
• Low-Pass Filter
  Built-in/Fixed
• Sensor Cleaning
  EOS integrated cleaning system
• Colour Filter Type
  Primary Colour
• Sensor Shift-IS
  Yes, up to 8-Stops advantage depending on the lens used 1

Image Processor

• Type
  DIGIC X

Lens

• Lens Mount
  RF (EF and EF-S lenses can be attached using: Mount Adapter EF-EOS R
  Control Ring Mount Adapter EF-EOS R
  Drop-In Filter Mount Adapter EF-EOS R)
  EF-M lenses are not compatible
• Focal Length
  Equivalent to 1.0x the focal length of the lens with RF and EF lenses 1.6x with EF-S

Focusing

• Type
  Dual Pixel CMOS AF II
• AF System / Points
  100% horizontal and 100% vertical with Face + Tracking and Auto Selection modes 100% horizontal and 90% vertical with manual selection and large zone modes 2
• AF Working Range
  EV -6.5 – 20 (at 23°C & ISO100) 3
• AF Modes
  One Shot Servo AF AI Focus AF (in A+ Scene Intelligent Auto mode )
• AF Point Selection
  Automatic selection: Face + tracking. 1053 Available AF areas when automatically selected
  Manual selection: 1-point AF (AF frame size can be changed) 6072 (stills)/ (4968) movie AF positions available
  Manual selection: AF point Expansion 4 points (up, down, left, right)
  Manual selection: AF point Expansion surrounding points
  Manual selection: Zone AF (all AF points divided into 9 focusing zones)
  Manual selection: Large Zone AF (Vertical)
  Manual selection: Large Zone AF (Horizontal)
• AF Tracking
  Humans, Animals (Dogs, Cats and Birds) or Vehicles (Racing cars or Motor bikes)
• AF Lock
  Locked when shutter button is pressed halfway or AF ON is pressed in One Shot AF mode. Using customised button set to AF stop in AI servo
• AF Assist Beam
  Emitted by built in LED or optional dedicated Speedlite (flash)
• Manual Focus
  Selected on lens

Exposure Control

• Metering Modes
  Real-time with image sensor, 384-zone metering.
  (1) Evaluative metering (linked to All AF points)
  (2) Partial metering (approx. 5.8% of viewfinder at centre)
  (3) Spot metering: Centre spot metering (approx. 2.9% viewfinder at centre)
  AF point-linked spot metering not provided
  (4) Centre weighted average metering
• Metering Brightness Range
  EV -3 – 20 (at 23°C, ISO100, with evaluative metering)
• AE Lock
  Auto: AE lock takes effect when focus is achieved
  Manual: By AE lock button in P, Av, Fv, Tv and M modes
• Exposure Compensation
  +/-3 EV in 1/3 or 1/2 stop increments (can be combined with AEB)
• AEB
  +/-3 EV in 1/3 or 1/2 stop increments
• Anti-flicker Shooting
  Yes. Flicker detected at a frequency of 100 Hz or 120 Hz. Maximum continuous shooting speed may decrease

• ISO Sensitivity

  Open
  Auto 100-102400 (in 1/3-stop or 1 stop increments)
  ISO can be expanded to L:50, H:204,800

Shutter

• Type
  Electronically-controlled focal-plane shutter and Electronic shutter function on sensor
• Speed
  30-1/8000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
• Shutter Release
  Soft touch electromagnetic release

White Balance

• Type
  Auto white balance with the imaging sensor
• Settings
  AWB (Ambience priority/White priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting
  White balance compensation:
  1. Blue/Amber +/-10
  2. Magenta/Green +/-10
• Custom White Balance
  Yes, 1 setting can be registered – From image or Live View
• WB Bracketing
  +/-3 levels in single level increments
  3, 2, 5 or 7 bracketed images per shutter release
  Selectable Blue/Amber bias or Magenta/Green bias

Viewfinder

• Type
  0.5-inch OLED colour EVF
• Dot Count
  3.69 Million dots
• Coverage (Vertical/Horizontal)
  Approx. 100%
• Magnification
  Approx. 0.76x 4
• Eyepoint
  Approx. 23mm (from eyepiece lens centre)
• Dioptre Correction
  -4 to +2 m-1 (dioptre)
• Display Performance
  Power saving: 59.94 fps Smooth 119.98 fps , supress low frame rate 60 -119.8fps⁵
• Viewfinder Information
  Shutter speed, Aperture, ISO speed, AF point information, Exposure level indicator, Number of remaining exposures, Exposure compensation, Battery level, Electronic shutter, HDR shooting, Highlight tone priority, Multiple-exposure shooting, Self-timer shooting mode, Maximum burst, AF method, Exposure simulation, Drive mode, AEB, Metering mode, FEB, Anti-flicker shooting, Still/video cropping, Shooting mode, Aspect ratio, Scene icons Auto Lighting Optimizer, AE lock Picture Style, Flash-ready, White balance, FE lock, Image Quality, High-speed sync, Bluetooth function, Wi-Fi on/off, , Histogram, Electronic level, Focus distance scale in manual focus, IS system, Audio Level – Manual (video), recording time remaining (video), headphone level (video), Video recording resolution frame rate and compression (video) Rec indicator (video)
• Depth of Field Preview
  Yes, via customised button
• Eyepiece Shutter
  N/A

LCD Monitor

• Type
  7.5cm (3.0″) Clear View LCD II, approx. 1.62 million dots
• Coverage
  Approx. 100%
• Viewing Angle (Horizontally/Vertically)
  Approx. 170° vertically and horizontally
• Coating
  Anti-smudge.
• Brightness Adjustment
  Manual: Adjustable to one of seven levels
  Colour Tone Adjustment: 4 settings
• Touch Screen Operations
  Capacitive method with menu functions, Quick Control settings, playback operations, and magnified display. AF point selection in still and Movies, touch shutter is possible in still photo shooting.
• Display Options
  (1) Basic Camera settings
  (2) Advance Camera settings
  (3) Camera settings plus histogram and dual level display
  (4) No info
  (5) Quick Control Screen

Flash

• Modes
  E-TTL II Auto Flash, Metered Manual
• X-Sync
  1/200sec mechanical shutter / 1/250th electronic 1st curtain
• Flash Exposure Compensation
  +/- 3EV in 1/3 or 1/2 stop increments with EX series Speedlite flashes
• Flash Exposure Bracketing
  Yes, with compatible External Flash
• Flash Exposure Lock
  Yes
• Second Curtain Synchronisation
  Yes via Speedlite
• HotShoe / PC Terminal
  Yes/No
• External Flash Compatibility
  E-TTL II with EX series Speedlite, wireless multi-flash support
• External Flash Control
  via camera menu screen

Shooting

• Modes
  Stills; Scene Intelligent Auto, Flexible priority AE, Program AE, Shutter priority AE, Aperture priority AE, Manual, Bulb and Custom (x3)
  Movie: Auto Exposure, Manual
• Picture Styles
  Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)
• Colour Space
  sRGB and Adobe RGB
• Image Processing
  Highlight Tone Priority (2 settings)
  Auto Lighting Optimizer (3 settings)
  Long exposure noise reduction
  Clarity
  High ISO speed noise reduction (4 settings) (stills and video)
  Lens optical correction
  – Peripheral illumination correction, Chromatic aberration correction Distortion correction (during/after still photo shooting, during video only)
  Diffraction correction,
  Digital Lens Optimizer (during/after still photo shooting only)
  Resize to M, S1, S2
  Cropping of images (JPEG/HEIF)
  – Aspect ratios 3:2, 4:3, 16:9, 1:1
  – Switch between vertical and horizontal cropping orientation
  – Image straightening
  – Cropping frame can be moved using touch screen operation
  RAW image processing
  Multiple exposure
  HDR
  HEIF to Jpeg conversion
• Drive Modes
  Single, Continuous High+, Continuous High, Continuous Low, Self timer (2s+remote, 10s+remote)
• Continuous Shooting
  Max. Approx. 12fps. with Mechanical shutter, speed maintained for 1000+ JPEG or 240 RAW images.Max. Approx. 20fps. with Electronic shutter67, speed maintained for 1000+ JPG or 120 RAW images
• Interval Timer
  Built in

File Type

• Still Image Type
  JPEG: 2 compression options
  RAW: RAW, C-RAW 14 bit (14-bit with Mechanical shutter and Electronic 1st Curtain, 12-bit A/D conversion with Electronic shutter, Canon original RAW 3rd edition)
  HEIF: 10bit HEIF is available in HDR shooting with
  [HDR PQ] set to [Enable]
  Complies with Exif 2.31 and Design rule for Camera File system 2.0
  Complies with Digital Print Order Format [DPOF] Version 1.1
• RAW+JPEG Simultaneous Recording
  Yes, any combination of RAW + JPEG or RAW + HEIF possible
• Image Size
  JPEG / HEIF
  3:2 ratio (L, RAW, C-RAW) 5472 x 3648, (M) 3648 x 2432, (S1) 2736 x 1824, (S2) 2400 x 1600
  1.6x (crop) (L) 3408 x 2272, (S2) 2400 x 1600
  4:3 ratio (L) 4864×3648, (M) 3248×2432, (S1) 2432 x 1824, (S2) 2112 x 1600
  16:9 ratio (L) 5472 x 3072, (M) 3648 x 2048, (S1) 2736 x 1536, (S2) 2400 x 1344
  1:1 ratio (L) 3648 x 3648, (M) 2432 x 2432, (S1) 1824 x 1824, (S2) 1600 x 1600
• Folders
  New folders can be manually created, named and selected
• File Numbering
  (1) Consecutive numbering
  (2) Auto reset
  (3) Manual reset
• File Naming
  2 User presets
