Epson L6170 Wi-Fi Duplex All-in-One Ink Tank Printer with ADF Specification
Print : | |
Printing Technology | Precision Core Printhead |
Print Speed | 20 ppm (Draft A4 Color) 33 ppm (Draft A4 Black) 8 ipm (ISO A4 Color) 15 ipm (ISO A4 Black)6.5 ipm (ISO A4 Color Duplex) 4.5 ipm (ISO A4 Black Duplex) |
Print Resolution | 4800 x 1200 dpi (with Variable-Sized Droplet Technology) |
2-sided printing | Automatic |
Copy : | |
Copy Speed | ISO 29183, A4 5.5 ipm (Color) 11 ipm (Black) |
Max Copies | 99 copies |
Copy Resize | 25 – 400% |
Copy Resolution | 600 x 1200 dpi |
Scan : | |
Scan Type | Flatbed color image scanner |
Sensor Type | Contact image sensor (CIS) |
Resolution | Optical : 1200 x 2400 dpi |
Max Document Size | 216 x 297 mm (8.5 x 11.7”) |
Bit Depth | Color : 48-bit input, 24-bit output Grayscale : 16-bit input, 8-bit output Black & White : 16-bit input, 1-bit output |
Scan Speed | 12 sec. (Black)/ 27 sec. (Color) 5.0 ppm (ADF/Simplex) |
Paper Handling | Input 150 sheets
Output 30 sheets ADF 30 pages (75 g/m2) |
Paper Size | Legal, 8.5 x 13 “, Letter, A4, 195 x 270 mm, B5, A5, A6, 100 x 148 mm, B6, 5 x 7 “, 4 x 6 “, Envelopes #10, DL, C6 |
Interface | USB 2.0, Ethernet, Wi-Fi IEEE 802.11b/g/n, Wi-Fi Direct |
Mobile/Cloud Printing | Epson iPrint, Epson Email Print, Remote Print Driver, Scan to Cloud, Apple AirPrint, Google Cloud Print, Mopria Print Service |
LCD Screen | 2.4 ” Color LCD |
Warranty | 1 year |
Epson L6170 Wi-Fi Duplex All-in-One Ink Tank Printer with ADF
Printer Type:
Printer Type:Print, Scan, Copy with ADF
Printing Technology:
Print Method:PrecisionCore PrintheadMinimum Ink Droplet Volume:3.3 plPrinter Language:ESC / P-RPrint Direction:Bi-directional printing, Uni-directional printingNozzle Configuration:400 nozzles Black, 128 nozzles per colour (Cyan, Magenta, Yellow)Maximum Resolution:4800 x 1200 dpi (with Variable-Sized Droplet Technology)Automatic 2-sided Printing:Yes (up to A4)
Print Speed:
Photo Default – 10 x 15 cm / 4 x 6 ” *2:Approx. 69 sec per photo (Border) *1
Approx. 92 sec per photo (Borderless) *1Draft, A4 (Black / Colour):Up to 33 ppm / 20 ppm *1ISO 24734, A4 Simplex (Black / Colour):Up to 15 ipm / 8.0 ipm *1ISO 24734, A4 Duplex (Black / Colour):Up to 6.5 ipm / 4.5 ipm *1
Copy Function:
Reduction / Enlargement:25 – 400%, Auto Fit FunctionMaximum Copy Size:A4, LetterCopy Resolution:600 x 1200 dpiMax Copies:99 copies
Copying:
Copy Quality:Normal / Best qualityISO 29183, A4 Simplex Flatbed (Black / Colour):Up to 11 ipm / 5.5 ipm
Scanning:
Scanner Type:Flatbed colour image scannerSensor Type:CISOptical Resolution:1200 x 2400 dpiMaximum Scan Area:216 x 297 mm (8.5 x 11.7 “)Scanner Bit Depth (Colour):48-bit input, 24-bit outputScanner Bit Depth (Grayscale):16-bit input, 8-bit outputScanner Bit Depth (Black & White):16-bit input, 1-bit outputScan Speed (Flatbed / ADF (Simplex)):200dpi, Black: 12 sec / 5.0 ppm
200dpi, Colour: 27 sec / 5.0 ppm
ADF Specifications:
Support Paper Thickness:64-95 g/m2Paper Capacity:30 pages (75 g/m2)
Paper Handling:
Number of Paper Trays:1 (Paper Cassette)Standard Paper Input Capacity:150 sheets, A4 Plain Paper (80 g/m2)
20 sheets, Premium Glossy Photo PaperOutput Capacity:30 sheets, A4 Plain Paper
20 sheets, Premium Glossy Photo PaperMaximum Paper Size:215.9 x 1200 mm (8.5 x 47.24 “)Paper Feed Method:Friction feedPaper Size:Legal, 8.5 x 13 “, Letter, A4, 195 x 270 mm, B5, A5, A6, 100 x 148 mm, B6, 5 x 7 “, 4 x 6 “, Envelopes #10, DL, C6Print Margin:0 mm top, left, right, bottom via custom settings in printer driver *3
Mobile and Cloud Solutions:
Epson Connect Features:Epson iPrint, Epson Email Print, Remote Print Driver, Scan to CloudOther Mobile Solutions:Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported OS and Applications:
Supported OS:Windows XP / XP Professional x 64 Edition / Vista / 7 / 8 / 8.1 / 10
Windows Server 2003 / 2008 / 2012 / 2016
Only printing and scanning functions are supported for Windows Server OS
Mac OS X 10.6.8 or later
Noise Level:
PC Printing/ Premium Glossy Photo Paper Best Photo:5.1 B(A) / 38 dB(A)PC Printing / Plain Paper Default*4:6.4 B(A) / 52 dB(A)
Dimensions and Weight:
Dimensions (W x D x H):375 x 347 x 231 mmWeight:6.7 kg
Consumables:
Black Ink Bottle:7,500 pages *5 – C13T03Y100Cyan Ink Bottle:6,000 (Composite Yield) *5 – C13T03Y200Magenta Ink Bottle:6,000 (Composite Yield) *5 – C13T03Y300Yellow Ink Bottle:6,000 (Composite Yield) *5 – C13T03Y400L6000 Series Maintenance Box:C13T04D100
Electrical Specifications:
Rated Voltage:220 – 240VRated Frequency:50 – 60 HzOperating:12.0 WSleep:0.9 WPower Off:0.3 WStandby:5.3 W
Interface:
USB:USB 2.0Network:Ethernet, Wi-Fi IEEE 802.11b/g/n, Wi-Fi DirectNetwork Protocol:TCP/IPv4, TCP/IPv6, LPD, IPP, PORT9100, WSDNetwork Management Protocols:SNMP, HTTP, DHCP, BOOTP, APIPA, PING, DDNS, mDNS, SLP, WSD, LLTD
Control Panel:
LCD Screen:2.4 ” Colour LCD
