Ubiquiti US-16-150W-EU | UniFi Switch

Ubiquiti US-16-150W which has features like 16 Gigabit Ethernet ports and 2 SFP ports.
Plus, supports 802.3af/at PoE+ or 24V passive PoE and has 36 Gbps switching capacity, 26.78 Mpps forwarding rate, 150W, etc.
Most important, we offer this UniFi switch cheap, in addition to it, if you buy from us, we will serve with free delivery in Dubai. Our company is Ubiquiti Networks distributor in UAE

SKU: US-16-150W-EU

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

88.80$

Out of stock

Out of stock

13 People watching this product now!
  • Pick up from the Woodmart Store

To pick up today

Free

  • Courier delivery

Our courier will deliver to the specified address

2-3 Days

Free

  • DHL Courier delivery

DHL courier will deliver to the specified address

1-3 Days

Free

  • Warranty 1 year
  • Free 30-Day returns

Payment Methods:

Description

Product specifications
16 x Gigabit RJ45 ports
2 x 1 Gbps SFP ports
Maximum power consumption: 150W (excluding PoE Output: 28W)
Supports POE + IEEE 802.3at/af and 24V Passive PoE
Max Deliverable PoE: 150W
Forwarding rate: 26.78Mpps
Dimensions 443 x 43 x 221 mm (17.44 x 1.69 x 8.70″)
Without Mounting Brackets 2.80 kg (6.17lbs)
With Mounting Brackets 2.89 kg (6.37lbs)
Total Non-Blocking Throughput 18 Gbps
Switching Capacity 36Gbps
Forwarding Rate 26.78Mpps
Including PoE Output 150W
Excluding PoE Output 28W
Networking Interfaces 16 x 10/100/1000 Mbps RJ45 Ethernet Ports / (2) 1 Gbps SFP Ethernet Ports
Management Interface  1 x RJ45 Serial Port Out-of-Band (Reserved for Future Use), Ethernet In-Band
Certifications CE, FCC, IC
Rack Mount Yes, 1U High
ESD/EMP Protection Air: ±24kV / Contact: ±25kV
Operating Temperature -5 to 40°C (23 to 104°F)
Operating Humidity 5 to 95% non-condensing
Shock and Vibration ETSI300-019-1.4 Standard
PoE Per Port
PoE Interfaces
PoE+ IEEE 802.3af/at (Pins 1,2+;3,6-)
24VDC Passive PoE (Pins 4,5+;7,8-)
Max. PoE+ Wattage per Port by PSE 34.2W
Voltage Range 802.3at Mode  50-57V
Max. Passive PoE Wattage per Port 17W
24V Passive PoE Voltage Range 20-27V
Product Includes
1 x UniFi Switch US-16-150W
1 x Power Cord
2 x Rack-Mount Brackets
8 x M4 Bracket Screws
4 x #10-32 x 5/8″ Mounting Screws
4 x #10-32 x 5/8″ Cage Nuts
1 x Quick Start Guide
