Yealink EXP43 Color Expansion Module

Yealink EXP43 Color Expansion Module

User-friendly Structure Design

With a 4.3-inch colour screen, the Yealink EXP43 expansion module is intended to bring a fresh visual experience and an easy operating experience to you. Its new design for the Stand enables you to adjust between two lying angles easily even without disassembling it. To ensure higher reliability of data transmission and a higher speed of data refresh, a USB cable is chosen to connect the EXP43 expansion module to Yealink T43U/T46U/T48U IP phones. Moreover, after the connection between the expansion module and the IP phone is established, the remaining USB port on the back of EXP43 can also be used for the phone’s extended functions, for example, call recording via USB flash drive, etc.

Intuitive Visualisation

A 4.3-inch 272×480-pixel colour screen greatly enriches your visual experience. The colour icons for DSS keys and the Wallpaper and Screensaver features both offer you a new operating experience as well as allow you to customise the EXP43 in your own style. In addition, the 3 independent control buttons with illuminated LED are used for fast switching to the corresponding page.

High Expansibility

The Yealink T43U/T46U/T48U IP phones can be fully equipped with up to three EXP43 Colour Expansion Modules while adding a maximum of 180 additional buttons. Three pages of 20 flexible buttons with dual-colour LED shown on the display can be programmed using up to 60 various features for speed dialling, BLF/BLA, call forward, transfer, etc. Thus, it will help you effectively manage a high volume of concurrent calls, effortlessly monitor calls and greatly boost personal productivity

Display

• 4.3″ 272×480-pixel colour display with backlight
• 16 bit depth colour
• Three page views are possible
• Different colour icons for each function shown on the LCD

Features Keys and Indicator

• 20 physical keys each with a dual-colour LED
• 40 additional keys through page switch
• 3 independent control keys with illuminated LED are used for fast switching pages
• Programmable for shared line, BLF List, call park, conference, forward, group pickup, group listening, LDAP, XML Browser

Features

• Wallpaper, screensaver, power saving
• Stand with 2 adjustable angles
• For support of two or three Expansion Modules, an external Yealink power adapter (5V/2A) is required.
• Up to three EXP43 can be attached on Yealink T43U/T46U/T48U IP phones
• USB port (2.0 compliant) for data in and out
• USB port (2.0 compliant) for:
  – wired/wireless USB headset
  – Wi-Fi through WF40/WF50
  – USB call recording through USB flash drive
• Max power consumption (PSU): 1.5W
• Dimension (W*D*H*T): 196.5mm*124.0mm*137.5mm*42.6mm
• Applies to Yealink T43U/T46U/T48U
• Operating temperature: 0~40°C (+32~104°F)
• Operating humidity: 10~95%
