| Unique Feature |
ASRock Super Alloy |
|
– Premium 50A Power Choke |
|
– Sapphire Black PCB |
|
– High Density Glass Fabric PCB |
|
ASRock Full Spike Protection (for all USB, Audio, LAN Ports) |
|
ASRock Live Update & APP Shop |
| CPU |
– Supports 10th Gen Intel® Core™ Processors and 11th Gen Intel® Core™ Processors (LGA1200) |
|
– 5 Power Phase design |
|
– Supports Intel® Turbo Boost Max 3.0 Technology |
|
|
| Chipset |
– Intel® H510 |
| Memory |
– Dual Channel DDR4 Memory Technology |
|
– 2 x DDR4 DIMM Slots |
|
– Supports DDR4 3200 / 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory* |
|
– Supports ECC UDIMM memory modules (operate in non-ECC mode) |
|
– Max. capacity of system memory: 64GB** |
|
– Supports Intel® Extreme Memory Profile (XMP) 2.0 |
|
*11th Gen Intel® Core™ (i9/i7/i5) support DDR4 3200 natively; Core™ (i3), Pentium® and Celeron® support DDR4 2666 natively. |
|
10th Gen Intel® Core™ (i9/i7) support DDR4 2933 natively; Core™ (i5/i3), Pentium® and Celeron® support DDR4 2666 natively. |
|
**Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation. |
| BIOS |
– 128Mb AMI UEFI Legal BIOS with multilingual GUI support |
|
– ACPI 6.0 Compliant wake up events |
|
– SMBIOS 2.7 Support |
|
– CPU Core/Cache, CPU GT, VCCSA, DRAM, VCCIO, CPU Standby, VCCIN AUX Voltage Multi-adjustment |
| Graphics |
– 11th Gen Intel® Core™ Processors support Intel® Xe Graphics Architecture (Gen 12). 10th Gen Intel® Core™ Processors support Gen 9 Graphics |
|
– Dual graphics output: support HDMI and D-Sub ports by independent display controllers |
|
– Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096×2160) @ 60Hz with 11th Gen Intel® Core™ Processors |
|
– Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096×2160) @ 30Hz with 10th Gen Intel® Core™ Processors |
|
– Supports D-Sub with max. resolution up to 1920×1200 @ 60Hz |
|
– Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Port (Compliant HDMI monitor is required) |
|
– Supports HDCP 2.2 with HDMI Port (HDCP 2.3 ready with 11th Gen Intel® Core™ Processors) |
|
*Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. |
|
Graphics specifications may vary between CPU types. |
| Audio |
– 7.1 CH HD Audio (Realtek ALC887/897 Audio Codec) |
|
– Supports Surge Protection |
| LAN |
– PCIE x1 Gigabit LAN 10/100/1000 Mb/s |
|
– 1 x Realtek RTL8111H |
|
– Supports Wake-On-LAN |
|
– Supports Lightning/ESD Protection |
|
– Supports Energy Efficient Ethernet 802.3az |
|
– Supports PXE |
| Slots |
11th Gen Intel® Core™ Processors |
|
– 1 x PCI Express 4.0 x16 Slot* |
|
10th Gen Intel® Core™ Processors |
|
– 1 x PCI Express 3.0 x16 Slot* |
|
– 1 x PCI Express 3.0 x1 Slot |
|
*Supports NVMe SSD as boot disks |
| Storage |
– 4 x SATA3 6.0 Gb/s Connectors, support Intel® Rapid Storage Technology 18, NCQ, AHCI and Hot Plug |
| Connector |
– 1 x SPI TPM Header |
|
– 1 x Chassis Intrusion and Speaker Header |
|
– 1 x CPU Fan Connector (4-pin)* |
|
– 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** |
|
– 1 x 24 pin ATX Power Connector |
|
– 1 x 8 pin 12V Power Connector |
|
– 1 x Front Panel Audio Connector |
|
– 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) |
|
– 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) |
|
*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. |
|
**The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. |
|
CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. |
| Rear Panel I/O |
– 1 x PS/2 Keyboard Port |
|
– 1 x PS/2 Mouse Port |
|
– 1 x D-Sub Port |
|
– 1 x HDMI Port |
|
– 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) |
|
– 4 x USB 2.0 Ports (Supports ESD Protection) |
|
– 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) |
|
– HD Audio Jacks: Line in / Front Speaker / Microphone |
| Software and UEFI |
Software |
|
– ASRock Motherboard Utility (A-Tuning) |
|
– ASRock XFast LAN |
|
UEFI |
|
– ASRock EZ Mode |
|
– ASRock Full HD UEFI |
|
– ASRock My Favorites in UEFI |
|
– ASRock Instant Flash |
|
– ASRock Internet Flash |
|
*These utilities can be downloaded from ASRock Live Update & APP Shop. |
| Support CD |
– Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar |
| Accessories |
– Quick Installation Guide, Support CD, I/O Shield |
|
– 2 x SATA Data Cables |
| Hardware Monitor |
– Fan Tachometer: CPU, Chassis/Water Pump Fans |
|
– Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans |
|
– Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans |
|
– CASE OPEN detection |
|
– Voltage monitoring: CPU Vcore, +12V, +5V, +3.3V |
| Form Factor |
– Micro ATX Form Factor: 7.76-in x 7.4-in, 19.7 cm x 18.8 cm |
|
– Solid Capacitor design |
| OS |
– Microsoft® Windows® 10 64-bit / 11 64-bit |
| Certifications |
– FCC, CE |
|
– ErP/EuP ready (ErP/EuP ready power supply is required) |
