BenQ MX550 XGA 3600 Lumens Dual HDMI Projector
Display
| Brightness (ANSI lumens) | 3600 |
| Native Resolution | XGA (1024×768) |
| Native Aspect Ratio | 4:03 |
| Contrast Ratio (FOFO) | 20000:1 |
| Display Color | 30 Bits (1,07 billion colors) |
| Light Source | Lamp |
| Light Source Life | Economic 10000 hrs, LampSave 15000 hrs, Normal 5000 hrs, SmartEco 10000 hrs |
Optical
| Throw Ratio | 1.96~2.15 |
| Zoom Ratio | 1.1x |
| Lens | F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm |
| Projection Offset (Full-Height) | 110% |
| Keystone Adjustment | 1D, Vertical ± 30 degrees |
| Picture Modes | 3D, Bright, Infographic, Presentation, sRGB, User 1, User 2 |
I/O Interface
| PC in (D-sub 15pin) | 1 |
| Monitor out (D-sub 15pin) | 1 |
| Composite Video in (RCA) | 1 |
| S-Video in (Mini DIN 4pin) | 1 |
| HDMI in | 2, HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4) |
| USB Type Mini B | 1 |
| RS232 in (DB-9pin) | 1 |
Audio
| Audio in (3.5mm Mini Jack) | 1 |
| Audio out (3.5mm Mini Jack) | 1 |
Environment
| Operating Temperature | 0~40℃ |
| Power Supply | AC 100 to 240 V, 50/60 Hz |
| Typical Power Consumption (110V) | ~270W |
| Acoustic Noise (Typ./Eco.)(dB) | 33/29 |
Accessories
| Carry Bag | Yes,5J.J3T09.001 (optioN/Al) |
| Remote Control w/ Battery | RCX014 |
| Power Cord (by region) | 1 (1.8M) |
| VGA(D-sub 15pin) Cable | (Standard), 1 (1.5m) |
| User Manual CD | 1 (24L) |
| 3D Glasses | (Optional), Yes, DGD5 |
| Quick Start Guide | 1 (18L) |
| Universal Ceiling Mount | (Optional), Yes, CMG3 |
Projection System
| Projection System | DLP |
*Lamp in this product contains mercury.
To dispose of the product or used lamps, consult your local environment authorities for regulations or see www.lamprecycle.org.
*Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specifications are subject to change without notice.
**Offset is calucated by full screen height.
