Blackmagic ATEM Mini Extreme ISO
Blackmagic ATEM Mini Extreme ISO
- 8-Channel HDMI Live Streaming Switcher
- Supports up to 1080p60
- RTMP Streaming via Ethernet or USB-C
- Record Program Out and Individual Inputs
- 11-Input, 2-Channel Audio Mixer
- Input Frame Rate and Format Converter
- Re-Sync on All HDMI Inputs
- HD Multiview Output with up to 16 Views
- Local and Software Switching
- 4 x Upstream, 2 x Downstream Keyers
Description
Blackmagic ATEM Mini Extreme ISO
| Model | Blackmagic ATEM Mini Extreme ISO |
| Available M/E Layers | 9 M/E |
| Effect Types | 2 x DVE |
| 4 x Luma Key | |
| 4 x Chroma Key | |
| Graphics Memory | 20 Images |
| Downstream Keys | 2 x Chroma, Luma, DVE |
| Generators | 5 x Pattern |
| 2 x Color | |
| Audio Mixing | 2-Channel Mixing |
Processing
| Switching Type | Pushbutton, Software |
| Processing Resolution | 1080p |
Input
| Number of Video Input Sources | 8 |
| Video Inputs | 8 x HDMI |
| Input Video Format | HDMI (10-Bit 4:2:2 YUV) |
| 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps | |
| 1080i 50/59.94/60 fps | |
| 720p 50/59.94/60 fps | |
| Audio Inputs | 2 x 1/8″ / 3.5 mm TRS Stereo Analog Female |
| Input Audio Format | Analog |
| Embedded Audio Input | HDMI: 2-Channel (per Input) |
Output
| Video Output Channels | 2 |
| Video Outputs | 2 x HDMI |
| Output Video Format | HDMI (10-Bit 4:2:2 YUV) |
| 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps | |
| Audio Outputs | 1 x 1/8″ / 3.5 mm TRRS Headphone/Microphone Stereo Analog Female |
| Embedded Audio Output | HDMI: 2-Channel |
| Multiview Output | 16-Way Multiview viaHDMI |
Connectivity
| Other I/O | 1 x RJ45 |
| 2 x USB-C | |
| HDCP Support | None |
| IP Video | H.264: |
| 1920 x 1080 Encoding | |
| Transport Protocols | RTMP |
| Simultaneous Streams | 1 Streams |
| Recording Modes | 1920 x 1080p up to 60 fps (MP4) |
Hardware
| OS Compatibility | macOS 10.15 |
| macOS 11.1 or Later | |
| Windows 10 | |
| *As of February, 2021: Check with manufacturer for the most up-to-date compatibility | |
| Wi-Fi | None |
| Bluetooth | None |
| Power I/O | 1 x Barrel (12 VDC) Input |
| Power Consumption | Device: 36 W |
General
| Dimensions | 14.56 x 5.37 x 1.56″ / 36.98 x 13.64 x 3.96Â cm |
| Weight | 2.72Â lb / 1.23Â kg |
Additional information
| brand | Blackmagic Design |
|---|---|
| Aperture | |
| Audio Capability | |
| Brand | |
| Compression Technology | |
| Display Resolution Maximum | |
| Duplex | |
| IR Range | |
| Lens | |
| Maximum Resolution | |
| Operating system | |
| Power Supply | |
| Print Media | |
| Printing Technology | |
| Refresh Rate | |
| Resolution | |
| SIP Account | |
| SIP Accounts | |
| Special Feature | |
| Water and Dust Resistant |
