Blackmagic ATEM Mini Pro
Blackmagic ATEM Mini Pro
- 4-Channel Live Stream HDMI Switcher
- Control up to Four BMPCC 6K/4K Cameras
- Live Tally, Stream, and Record Status
- Record Button, Channel Preview Multiview
- 2-Channel Digital Audio Mixer per Source
- HDMI Output, Ethernet ATEM Control
- Media Player, Computer Input Support
- Upstream and Downstream Keyers
- Color and Pattern Generators
- DVE Transition, Chroma/Luma Keyers
Description
Blackmagic ATEM Mini Pro Specifications:
| Model | Blackmagic ATEM Mini Pro |
| Available M/E Layers | 5 M/E |
| Effect Types | 1 x DVE, Graphic, Transition, Chroma Key, Alpha Key, Luma Key |
| Downstream Keys | 1 x Chroma, DVE |
| 2 x Luma | |
| Audio Mixing | 2-Channel Mixing |
| Switching Type | Pushbutton |
Input
| Number of Video Input Sources | 4 |
| Video Inputs | 4 x HDMI Female |
| Input Video Format | HDMI (10-Bit 4:2:2 YUV) |
| 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps | |
| 1080i 50/59.94/60 fps | |
| 720p 50/59.94/60 fps | |
| Audio Inputs | 2 x 1/8″ / 3.5 mm TRS Stereo Analog Female |
| Embedded Audio Input | HDMI: 2-Channel (per Input) |
Output
| Video Output Channels | 1 |
| Video Outputs | 1 x HDMI |
| Output Video Format | HDMI / RJ45 (10-Bit 4:2:2 YUV) |
| 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps | |
| Embedded Audio Output | HDMI: 2-Channel (per Output) |
| Multiview Output | Yes |
| Monitor Output | 1 x HDMI |
Connectivity
| Other I/O | 1 x RJ45 LAN, Sync, Tally, Timecode, Firmware, Control Input/Output |
| 1 x USB-C Firmware, Control Input/Output |
Hardware
| OS Compatibility | macOS 10.14 or Later |
| Windows 10 | |
| *As of April 2020: Check with the manufacturer for the most up-to-date compatibility | |
| Wi-Fi | None |
| Bluetooth | None |
| Power I/O | 1 x Barrel (12 VDC) Input |
| Power Consumption | 36 W |
General
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Storage Temperature | 14 to 140°F / -10 to 60°C |
| Operating Humidity | 0 to 90% |
| Dimensions | 9.35 x 4.07 x 1.38″ / 23.75 x 10.34 x 3.51Â cm |
| Weight | 19.4Â oz / 550Â g |
