Datalogic Magellan™ 3410VSi Vertical POS Barcode Scanner
The innovative Datalogic Magellan™ 3410VSi Vertical POS Barcode Scanner on-counter scanners from Datalogic are simple to use and bring best-in-class benefits to your operations. While outwardly identical, these products offer different levels of performance to suit all of your needs.
The Magellan 3410VSi is an entry-level imaging scanner, aimed to replace the best-selling 3200VSi product. The 3410VSi provides powerful performance at an attractive price. If you need more processing power and faster throughput, however, the high-end Magellan 3450VSi has the best scanning performance of any single-plane scanner on the market.
This scanner works well in a variety of applications, including retail point of sale, pharmacy, drug verification, and hands-free component verification. The extra-large reading area and sweep scanning provide a fast and easy reading from a variety of barcodes and other sources. The Magellan 3410VSi brings greater efficiency to your business.
Datalogic Magellan™ 3410VSi Vertical POS Barcode Scanner
General
| Brand | Datalogic |
| Model | Magellan 3410VSi | M3410-010210-07104 |
| Product | Barcode readers |
| EAN | 5,70417E+12 |
| Language | English |
| Filetype | EN – 32 (PDF) |
Scanning
| Type | Built-in bar code reader |
| Scanner type | 1D/2D |
| Sensor type | – |
| Linear (1D) barcodes supported | GS1 DataBar |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, GS1 Databar RSS14 Stacked, MicroPDF417, PDF417, QR Code |
| Light levels (direct sunlight) | 0 – 26100 lx |
Packaging Data
| Cables included | RS-232 |
Power
| Power source type | USB |
| Power consumption (typical) | 2.5 W |
| Input voltage | 100 – 240 V |
| Input frequency | 50-60 Hz |
Ports & interfaces
| Connectivity technology | Wired |
| Standard interfaces | RS-232, USB |
Performance
| Product colour | Black |
| LED indicators | ✓ |
| Buzzer | ✓ |
| International Protection (IP) code | IP52 |
| Print contrast | 25% |
Operational conditions
| Operating relative humidity (H-H) | 5 – 95 % |
| Operating temperature (T-T) | 10 – 40 °C |
| Storage temperature (T-T) | -40 – 70 °C |
Weight & dimensions
| Width | 137 mm |
| Depth | 152 mm |
| Height | 94 mm |
| Weight | 600 g |
| brand | Datalogic |
|---|---|
| Aperture | |
| Audio Capability | |
| Brand | |
| Compression Technology | |
| Display Resolution Maximum | |
| Duplex | |
| IR Range | |
| Lens | |
| Maximum Resolution | |
| Operating system | |
| Power Supply | |
| Print Media | |
| Printing Technology | |
| Refresh Rate | |
| Resolution | |
| SIP Account | |
| SIP Accounts | |
| Special Feature | |
| Water and Dust Resistant |
