SPECIFICATIONS
Model Name GeForce RTX™ 4060 VENTUS 2X BLACK 8G
OC
Graphics Processing Unit NVIDIA®
GeForce RTX™ 4060
Interface PCI Express®
Gen 4 x 8
Core Clocks
Extreme Performance: 2505 MHz (MSI
Center)
Boost: 2490 MHz
CUDA®
CORES 3072 Units
Memory Speed 17 Gbps
Memory 8GB GDDR6
Memory Bus 128-bit
Output
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR and
8K@60Hz HDR and Variable Refresh Rate
(VRR) as specified in HDMI™ 2.1a)
HDCP Support Y
Power consumption 115 W or 120 W
Power connectors 8-pin x 1
Recommended PSU 550 W
Card Dimension (mm) 199 x 120 x 41 mm
Weight (Card / Package) 546 g / 783 g
DirectX Version Support 12 Ultimate
OpenGL Version Support 4.6
Maximum Displays 4
G-SYNC®
technology Y
Digital Maximum Resolution 7680 x 4320
FEATURES
Dual Fan
Two fans and a huge heatsink ensure a cool and quiet experience
for you.
TORX FAN 4.0
A masterpiece of teamwork, fan blades work in pairs to create
unprecedented levels of focused air pressure.
Reinforcing Backplate
The reinforcing backplate features a flow-through design that
provides additional ventilation.
Zero Frozr
The fans completely stop when temperatures are relatively low,
eliminating all noise.
MSI Center
The exclusive MSI Center software lets you monitor, tweak and
optimize MSI products in real-time.
Afterburner
Take full control with the most recognized and widely used
graphics card overclocking software in the world.
