MSI VGA GeForce RTX 4070 Ti SUPER 16G EXPERT

SPECIFICATIONS
Model Name GeForce RTX™ 4070 Ti SUPER 16G EXPERT
Graphics Processing Unit NVIDIA®
GeForce RTX™ 4070 Ti SUPER
Interface PCI Express®
Gen 4
Core Clocks
Extreme Performance: 2685 MHz (MSI
Center)
Boost: 2670 MHz
CUDA®
CORES 8448 Units
Memory Speed 21 Gbps
Memory 16GB GDDR6X
Memory Bus 256-bit
Output
DisplayPort x 3 (v1.4a) HDMI™ x 1 (Supports
4K@120Hz HDR, 8K@60Hz HDR, and Variable
Refresh Rate as specified in HDMI™ 2.1a)
HDCP Support Y
Power consumption 285 W
Power connectors 16-pin x 1
Recommended PSU 700 W
Card Dimension (mm) 312 x 141 x 61 mm
Weight (Card / Package) 1668g / 2636g
DirectX Version Support 12 Ultimate
OpenGL Version Support 4.6
Maximum Displays 4
G-SYNC®
technology Y
Digital Maximum Resolution 7680 x 4320

FEATURES
Flow Frozr
Stay cool and silent, MSI’s Flow Frozr thermal design enhances
graphics card heat dissipation.
Patented Fan Design
The unique design features a distinctive appearance and
enhances airflow to improve heat dissipation capability.
Copper Baseplate
Heat from the GPU and memory modules is captured by a copper
baseplate and then rapidly transferred to Core Pipes.
Core Pipe
Precision-machined heat pipes ensure max contact to the GPU
and spread heat along the full length of the heatsink.
V-shaped Fins
Fins with a V-shaped cutout influence airflow inclination angles,
which enhance flow efficiency.
Push Pull Airflow
Cooling efficiency is improved with two fans working
collaboratively to reduce heat buildup.
Aluminum Die-Casting
Overall structural integrity is enhanced with metal material while
the flow-through ventilation reduces trapped heat.
Zero Frozr
The fans completely stop when temperatures are relatively low,
eliminating all noise.
